Features
Finish
Bright Brass
Series
1600 Series
Use With
Cylindrical and Mortise Latchbolts and Deadbolts
Grade
Grade 1
Color Code
605/US3
Function
Field Selectable (Safe/Secure)
Fire Rated
3 Hours {A}, Yes
Amp Draw
.24 Amps at 12VDC, .12 Amps at 24VDC
Burglar Rated
Yes
Faceplate Shape
Flat Face, Square Corners
Faceplate Size
4-7/8 In. X 1-1/4 In.
Frame Application
Metal or Wood
Frame Depth
1-5/8 In.
Operating Voltage
12VDC/24VDC
Package Qty
1
Special Marks
Fire rated 3 Hours {A}
Base Material
Brass
Switch Type
None
Voltage
12/24 VDC
For Use With
All Brands of Cylindrical and Mortise Locksets With a Deadbolt
Application
Metal or Wood Frame
Warranty
SecuriCare 5 Year
Strength
1500 (Static); 70 (Dynamic) lb; ft-lb
Current Draw
240mA; 120mA
Finish Description
Bright Polished Brass
Product Height
4-7/8 Inch
Product Width
1-5/8 Inch Body, 1-1/4 Inch Faceplate
Finish Family
Polished Brass
Included Components
Kit includes faceplates and brackets to make 1N, 1ND, 1NM and 1NTD options.
Product Material
Stainless steel
Duty
Selectable Fail Safe/Fail Secure
Product Depth
1-5/8 Inch
Standards
ANSI/BHMA A156.31, Grade 1; UL 1034 Listed; UL 294 Listed; RoHS Compliant; UL 10C Listed; CAN/ULC-S104 Fire Door Conformant; NFPA-252 Fire Door Compliant; ASTM-E152 Fire Door Compliant; California Fire Marshal Listed; ANSI/SDI A250.13; ANSI-ASTM E330
Static Strength
1500 lbs.
Faceplate Dimension
4-7/8" x 1-1/4"
Function Family
Electric Strike
Dynamic Strength
70 Foot-Lbs.
Features
Tamper Resistant; Field Selectable Fail Safe/Fail Secure; Non-Handed; Interchangeable Faceplates and Accessories; Field Replaceable Components; Fully Finished Faceplate, Keeper, Case and Trim; Field Adjustable Integrated Shim
Product Type
Electric Strike
Manufacturer Parent
Assa Abloy
Sub-Series
HES-1600CDB
Faceplate
4-1/8"
Model
1600-CDB - Complete Electric Strike Pac
Door Type
Metal, Wood
Electronic
Yes
Holding Force
1500
Substrate Type
Stainless Steel
Product Width
1-3/4"
Lock Type
Mortise or Cylindrical
Preload Capable
No
Fail Safe / Fail Secure
Field Selectable
Endurance Cycles
1,000,000
Door Strike
1-5/8"
Latch Specification
Deadbolt
Outdoor Rated
Yes
Shim
Field adjustable
Windstorm Rated
Yes
Product Overview
Electric Strike, For Cylindrical or Mortise Latchbolt and Deadbolt Locks, Auto-sensing 12-24VDC, Field Selectable Fail Safe/Fail Secure, Includes 1N, 1ND, 1NM, 1NTD Options, Bright Brass
The HES 1600 Series heavy duty electric strike is the most advanced electric strike available on the market for cylindrical latchbolt and deadbolt locks. It accommodates up to a 1" deadbolt with enhanced vertical cavity spacing and will accommodate every brand of cylindrical or mortise lock designed to work with a 4-7/8" strike plate.
The most advanced electric strike available on the market for cylindrical latchbolt and deadbolt locks.
The 1600 Series accommodates up to a 1" deadbolt with enhanced vertical cavity spacing and will accommodate every brand of cylindrical or mortise lock designed to work with a 4-7/8" strike plate.
