30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Thickness
1-3/4 In.
Strike Number
10-001
Latch Number
11-085
Function
53-Entrance
Latch Type
Deadlatch
ANSI Function
F109
Special Marks
Conventional cylinder
Dust Box
Plastic
Strike Width
1-1/8 In.
Latch Backset Dim
2-3/8 In.
Cylinder Type
P-6 Pin Conventional (Keyed 5)
Lock Face Size
2-1/4 In. x 1 In.
Package Qty
1
Bolt Protection
1/2 In.
Color Code
626/US26D
Strike Type
T-Strike
Rose/Escutcheon Design
PLY - Plymouth
Keyway
Schlage C
Strike Height
2-3/4 In.
Lever/Knob Design
PLY - Plymouth
Finish
Satin Chrome
Backset
2-3/8 Inch, 1 x 2-1/4 Inch, Square Corner
Strike
T-Strike, 1-1/8 Inch x 2-3/4 Inch, 1-1/4 Inch Lip, Sq Corner
Design
Plymouth
Series
A Series
Grade
ANSI/BHMA Grade 2
Finish Description
Satin Chrome
Knob style
PLY-Plymouth
Keyblank Grouping
SCHL-C-6-1
Rose/Escutcheon Trim
Round Rose
Product Type
Cylindrical Lock
Projection
2.3125
Door Thickness
1 3/8" - 1 7/8"
Knob Diameter
2.1250
ADA Approved
False
Keying Charges
CCAM
Handing
Reversible
Warranty
3 Year Limited
Application
Schools; Hospitals; Hotels; Commercial Buildings; Institutional Buildings; Multi-Family Properties; Homes
Hand
Reversible
Handle Type
Knob
Rose Diameter
2-9/16 Inch
Latch Throw
1/2 Inch
ADA Compliant
No
Finish Family
Satin Chrome
Strike Size
1-1/8" x 2-3/4"
Standards
Meets or Exceeds A156.2 Series 4000, Grade 2 Strength and Operational Requirements; Meets Ff-H-106C; California State Reference Code
Cylinder Type Used
Conventional
Front Material
Steel
Function Description
Pushing and turning button on inside locks outside knob/lever requiring use of a key until button is manually unlocked.
Front Size
1" x 2-1/4"
Function Family
Entry/Entrance/Office
Strike Lip
1-1/8 Inch
Product Projection
2-5/16 Inch
Features
Cold-Rolled Steel, and Machined and Threaded Hubs Prevent Loosening of the Lockset by Bolting the Chassis to the Door; Heavy-Duty Cast Mounting Plate With Specially Tapped Holes, Keeps Lockset Tight on the Door
Manufacturer Parent
Allegion
Latch Corner
Square
Knob/Lever Size
2-1/8 Inch
Latch Bolt Material
Brass
Knob Style Family
Round Flat Knob
Sub-Series
CL_Cylindrical_Locks_schlage_commercial_174
Pack Size
1
Manufacturer Warranty
24012b42-6e6b-4629-9dcf-5cd7c3046911
Assembled Depth (in.)
1.88
Assembled Height (in.)
2.625
Assembled Width (in.)
3.63
Backset size (in.)
2-3/8 in
Certifications and Listings
No Certifications or Listings
Deadbolt strike width (in.)
1.75
Door Locks & Knobs Product Type
Keyed Handlesets
Required door thickness (in.)
1-3/8 in
Security/ANSI Grade
ANSI Grade 3 (Good)
The A Series cylindrical lock is Schlage's first lock and continues to exceed ANSI/BHMA Grade 2 standards, allowing it to be used in a wide range of commercial and residential applications. A Series locks are available in ten finishes and five trim designs allowing it to fit any new or existing environments.
Specifications: Handing:
