Schlage Commercial 09-663 622 Armor Front and Screws for L9050, L9060, L9070, or L9080 Matte Black Finish
Item #: 09-663 622 by Schlage Commercial
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- L Series
- Handing: L9000 Series lock bodies are field-reversible without disassembly. L400 Series locks are non-handed.
- Door Thickness: 1 3/4” (44 mm) standard. 1 3/8” (35 mm) to 2 1/2” (64 mm) optional. Over 2 1/2” (64 mm) door ranges vary by function. No escutcheon available for 1 3/4” (44 mm) doors standard. 2” to 2 3/8” (51 mm to 60 mm) optional. Specify door thickness if other than 1 3/4”.
- Certified Schlage Parts
- Backset: 2-3/4” (70 mm) only.
- Armored Front: L9000 Series: 1 1/4” x 8” x 7/32” (32 mm x 203 mm x 6 mm) standard. 1 1/16” x 8” x 1 7/32” (27 mm x 203 mm x 6 mm) optional. L400 Series: 4 7/16” x 3 5/8” x 1” (113 mm x 92 mm x 25 mm)
- Made With Strong Materials
- Many Parts Are Finish Specific
- Case Size: L9000 Series: 4 7/16” x 6 1/16” x 1” (113 mm x 154 mm x 25 mm) L400 Series: 4 7/16” x 3 5/8” x 1” (113 mm x 92 mm x 25 mm)
- Spacing: Knob or lever to cylinder, 3 7/8” (98mm); knob or lever to thumbturn hub, 2 11/16” (68mm).
- Bolts: 1” (25mm) throw stainless steel deadbolt and 3/4” (19mm) throw stainless steel latch with anti-friction tongue.
- Exposed Trim
- Knobs: #41 and #42 heavy-duty wrought brass, bronze or stainless steel knobs match D-Series knobs.
- Levers: Forged brass or bronze and cast stainless steel. Designs available to match D-Series levers. 93 Lever Design: Extruded brass, bronze or stainless steel.
- Escutcheons: L escutcheons are cold-forged brass or bronze and stainless steel. N escutcheons are heavy wrought reinforced brass, bronze and stainless steel.
- Trim Combinations: Available with knob both sides, lever both sides, or knob and lever with rose or escutcheon both sides.
- Strike: L9000 Series: ANSI curved lip strike 1 1/4” x 4 7/8” (32 mm x 124 mm) x 1 3/16” (30 mm) lip to center with dust box standard. L400-Series: 1 1/8” x 3 5/8” (29 mm x 92 mm) with dust box.
- Cylinder & Keys: 6-pin Everest C123 keyway cylinder with two patented keys standard.
- Keying Options: Interchangeable core and Primus high security cylinders. Master keying, grand master keying and construction keying.
Finish
Matte Black
Series
L Series
Color
Flat Black Coated
Color Code
622/US19
For Use With
L9050; L9056; L9060; L9070; L9071; L9080; L9082
Warranty
Limited Lifetime Mechanical/Finish
Function
Mortise Armor Front
Door Thickness
1-3/4 inch
Finish Description
Matte Black
Product Width
1-1/4 Inch
ADA Compliant
No
Corner Type
Square
Finish Family
Black
Included Components
(2) Screws
Product Material
Mild Steel
Standards
UL Listed
Front Size
1-1/4 Inch
Function Family
Part/Component
Product Type
Lock Part/Accessory
Manufacturer Parent
Allegion
Sub-Series
PA_Locks_Parts_schlage_commercial_74
Aluminium Bottle Contents
Swinging
ProductType
Manual
Alternate Part Number-1
193781
Dimension
1-1/4" x 8"
Material
Steel
Manufacturer Warranty
Limited 10 Year Mechanical and 3 Year Electro Mechanical Warranty
Hazardous Material
No
Finish code
622
Latch Faceplate Dimension
1-1/4" x 8"
No of inners
1
Product Overview
L9050/56/60/70/71/80/82/90/91/92/93/94/95 Latch x Aux Latch, 1-1/4 In. Wide, Flat Black Coated
Lock bodies are field-reversible without disassembly
Schlage L Series Extra Heavy Duty, Grade 1 Mortise Locks are built to withstand the rigors of daily use without fail. Lock bodies are field-reversible without disassembly.
