Yale Commercial AU548F 626 Augusta Active Lever Passage Rose Exit Device Trim US26D (626) Satin Chrome Finish
Item #: AU548F 626 by Yale
UPC #: 049306038584
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- ANSI / BHMA A156.3 Grade 1
- UL Listed for Use on Fire Doors Having a Rating up to 3 Hours
- Featuring Yale Free Wheeling Lever Mechanism
- Designed and Manufactured Under a Certified ISO 9001 Quality System
- Limited 5 Year Warranty
Finish
Satin Chrome
Function
Passage
Series
7000 Series Trim
Design
Augusta
Trim Design
Rose with Lever
Fire Rated
No
Package Qty
1
Trim Type
Passage Lever
Color Code
626/US26D
Finish Description
Satin Chrome
Lever Style
AU-Augusta
Product Type
Exit Device Trim
Handing
Non-Handed
Device Type
Rim, SVR or CVR
Warranty
3 yr Limited
Aluminium Bottle Contents
Swinging
ProductType
Manual
Lever Height
3-1/2 Inch
Device Trim ANSI Function
02/14
Manufacturer Parent
Assa Abloy
For Use With
6100(F), 6150(F), 6160(F), 6170(F), 6100ED(F), 6150ED(F), 6160ED(F), 6170ED(F) Exit Devices
Hand
Non-Handed
Grade
ANSI/BHMA Grade 1
Sub-Series
EDT_Device_Trim_yale_commercial_9
Lever Style Family
Straight Return Lever
Trim Style
Rose Trim with Lever
ADA Compliant
No
Lever Length-Inches
5 Inch
Device Trim Function
Passage Lever; Dummy Trim Free-Wheeling Lever
Function Family
Passage Exit Device Trim
Standards
ANSI/BHMA A156.3, Grade 1 Certified
Product Projection
3-1/2 Inch
Features
Trim Through-Bolts; 1-3/4" Door Standard
Cylinder Type Used
Component
Finish Family
Satin Chrome
Dimension
5" Lever Length; 3" Projection; 3-1/2" Rose Diameter
Material
Aluminum
Door Thickness
1-3/4"
Manufacturer Warranty
Limited 3 Year Warranty
Includes Cylinder(s)
No
Hazardous Material
No
Finish code
626
Lever Knob Design
Augusta Lever
No of inners
1
Product Overview
540F Series rose trim. Certified ANSI/BHMA A156.3 Grade 1. Trim through-bolts to exit device for strength. 1-3/4 (44mm) door standard. For doors through 2-1/4 (57mm) or shim-mounted devices specify on order. Accepts cylindrical type cylinders.
