Grooving Insert: GIPY SNMA6.00-3.00 432RK5 IC804 WKK10S, Solid Carbide AlTiN

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

B Walter 6411649 Grooving Insert: GIPY SNMA6.00-3.00 432RK5 IC804 WKK10S, Solid Carbide AlTiN

Item #: 6411649 by B. Walter & Co.

See reviewsSee reviews
See reviews summary

$25.97

/each
SAVE UP TO 2.60
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

ANSI Code

GIPY 6.00-3.00 IC804

Overall Length (mm)

12.70

Standards

ANSI

Insert Material

Solid Carbide

Series

Cut Grip

Coating Process

CVD

Coating/Finish

AlTiN

Corner Radius (Decimal Inch)

0.0313

Manufacturers Catalog Number

6411649

Material Grade

Submicron

Overall Width (Decimal Inch - 4 Decimals)

0.1970

Primary Workpiece Material

Cast Iron

Primary Workpiece Material Code

K

Thickness (Inch)

3/16

Vendor Drop Ship

Y

Cutting Width (Decimal Inch)

0.2360

Insert Holding Method

Pin

Insert Thickness (Decimal Inch)

0.1875

Maximum Depth of Cut (Decimal Inch)

0.1969

Multi-use Tool

Yes

Overall Width (mm)

5.00

Rake

Negative

Secondary Workpiece Material

Hard Material

Single Or Double End

Double

Inscribed Circle (Decimal Inch)

0.5000

Rake Angle

0.00

Chip Breaker

RK5

Secondary Workpiece Material Code

H

Insert Style

GIPY

Insert Size Code

1204

Hole Diameter (Decimal Inch)

0.2020

Included Angle Degree

90

Inscribed Circle (Inch)

1/2

Maximum Depth of Cut (mm)

5.00

Manufacturer Grade

IC804

Maximum Depth Of Cut Range (Decimal Inch)

0.1500 to 0.2000

Maximum Depth Of Cut Range (mm)

5.00 to 10.00

Corner Radius (mm)

3.00

Cutting Width (mm)

6.00

Iso Code

GIPY 6.00-3.00 IC804

Maximum Corner Radius (Decimal Inch)

0.1180

Product Overview
Grooving Insert: GIPY SNMA6.00-3.00 432RK5 IC804 WKK10S, Solid Carbide AlTiN Finish, 6 mm Cutting Width, 5 mm Max Depth, Series Cut-Grip & Tiger-tec Silver
