BLUE SEA SYSTEMS 7059 30A Circuit Breaker Push-Button with Quick Connect Terminals

Item #: 7059 by Blue Sea Systems

Brand: BLUE SEA SYSTEMS

See reviewsSee reviews
See reviews summary
In Stock

$5.07

/each
SAVE UP TO 0.51
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 1000+ units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Custom Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Circuit Breaker Type: Thermal trip, manual push-button reset only
  • Voltage Compatibility: DC
  • Maximum Voltage: 32V DC
  • Interrupt Capacity: 3000A @ 14.7V, 2500A @ 28V
  • Safety Features: Trip Free" design cannot be held ON" during fault
  • Housing Material: Plastic
  • Housing Dimensions: 1-3/8"L x 5/8"W x 2-3/8"D
  • Terminal Type: 1/4" Male Quick Connect Terminals
  • Mounting Hardware: Mounts in 3/8" hole
  • Weight: 0.06lb (0.03 kg)
  • Approvals: UL 1077 -UL cUL (USA and Canada), TUV certified, UL 1500 and ISO 8846, CE Marked
  • Warranty: LIfetime

Type

Circuit Breakers

Warranty

One Year

Amperage

30 amps

Mounting Hardware

Circuit Breaker Panel (Sold Separately)

ISO Approved

UL 1077 -UL cUL (USA and Canada) , TUV Certified , UL 1500 and ISO 8846 , CE Marked

Product Overview
Provides economical circuit protection for 3 to 40 Amp loads when switching is provided elsewhere or not required. Compact, ignition protected design allows high density DC circuit protection in tight quarters. Push-to-reset, trip free" design cannot be held ON" during fault conditions. Optional waterproof boot provides additional circuit breaker protection in wet environments.
