Brushed Stainless AMR Series Patch Lock, Stainless Steel Material, 3/8" And 1/2" Glazing Thickness, Brushed Stainless Finish

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

CRL AMR205BS Brushed Stainless AMR Series Patch Lock, Stainless Steel Material, 3/8" And 1/2" Glazing Thickness, Brushed Stainless Finish

Item #: AMR205BS by CR Laurence

Brand: CRL

See reviewsSee reviews
See reviews summary
In Stock

$103.92

/each
SAVE UP TO 10.39
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 1023 units available

Finish: Brushed Stainless

QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Custom Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Constructed from a high density cast body with a lock mechanism and a brushed stainless steel finish for a consistent appearance.
  • Measures 2" in height and 6-7/16" in width, with a 5/8" diameter lock bolt and an 11/16" bolt length for standard door security.
  • Compatible with 3/8" and 1/2" glass thicknesses, including necessary gaskets for secure mounting on glass panels.
  • Versatile mounting options allow for installation on the top, bottom, or vertical edge of glass doors.
  • Requires specific glass fabrication including a 3/4" diameter hole and either a corner notch or U-cutout depending on mount type.
  • Designed for commercial and residential door hardware applications, including double door setups requiring a bottom patch lock.
  • Includes installation template and instructions; note that cylinders are not included and must be purchased separately.

Finish

Brushed Stainless

Lock Bolt Diameter

5/8" (16 mm)

Bolt Length

11/16" (17.5 mm)

Height

2

Width

6-7/16

Glazing Thickness

3/8, 1/2

Finish/Color

Brushed Stainless Steel

Product Overview
The Brushed Stainless AMR Series Patch Lock is a component for commercial and residential door hardware, designed for use on glass doors. This patch lock is constructed from a high density cast body with a lock mechanism, providing a functional solution for door security. It can be mounted on the top or bottom of doors, or on the vertical edge of the door, where it can be secured to a jamb using a keeper. The unit is compatible with 3/8" and 1/2" glass thicknesses, and includes gaskets for these applications. The lock bolt has a diameter of 5/8" and a bolt length of 11/16". The overall dimensions of the unit are 2" in height and 6-7/16" in width. Glass fabrication is required for installation: top or bottom mounts require one 3/4" diameter hole and one corner notch, while side mounts require one 3/4" diameter hole and one U-cutout. This lock is finished in brushed stainless steel. Please note that cylinders are not included and must be ordered separately. The unit comes with a template and instructions for installation.
