Cavity Sliders WEBKIT1240081 CS Cavity Sliders Pocket Door System
Item #: WEBKIT1240081 by Cavity Sliders
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Application
Standard Access Door, Pocket Door
Load Capacity
176 lb
Door Thickness
1 3/8 to 1 3/4 in
Door Width
36 to 42 in
Door Height
Max. 96 in
Door Material
Wood
Detailed Door Movement
Single sliding
Door Movement
Pocket Door
Soft-Close Type
Two-Way Operation
Soft-Closing
Yes
Product Overview
The CS Cavity Sliders Pocket Door Systems are for sliding wood doors weighing up to 500 lb (227 kg) each with options for SofStop soft-close mechanisms of up to 264 lb (120 kg) per door. Made for standard 2 x 4 wood and metal wall stud construction.
Features:
- Choose from a selection of pocket frames for door widths from 24 in (610 mm) to 48 in (1219 mm) and for door heights of up to 80 in (2030 mm) and 96 in (2438 mm)
- Pocket frames are made of sturdy double-wall aluminum including the upper running track, which can be cut to size to suit custom-size doors
- The frames are supplied disassembled for low-cost shipping and ease of installation
- Choose from a wide variety of carriage hardware sets with or without SofStop soft-close mechanism
- CarriSnap mounting suspension plate available for the top of the door for mounting and releasing the upper trolley without tools
- SoftStop soft-close mechanisms come in single or twin action for doors weighing up to 176 lb (80 kg), and single action for doors weighing up to 264 lb (120 kg)
- Trim clips are included in the pocket frame sets for easy press-on mounting of door jamb trim
- Features a pivoting bottom guide to ease loading the door into the pocket frame during installation
- Large wheel trolleys with precision ground bearings for smooth running
For basic pocket door kits without soft-close, see the Suggested Products section below for a direct link to CS Cavity Slider Pocket Door Kit.
Ideal for a wide variety of applications in residential, commercial, and institutional projects .
IMPORTANT: For 2 x 6 wall construction, see the CS Cavity Sliders Ultimate Pocket Door System.
Features:
- Choose from a selection of pocket frames for door widths from 24 in (610 mm) to 48 in (1219 mm) and for door heights of up to 80 in (2030 mm) and 96 in (2438 mm)
- Pocket frames are made of sturdy double-wall aluminum including the upper running track, which can be cut to size to suit custom-size doors
- The frames are supplied disassembled for low-cost shipping and ease of installation
- Choose from a wide variety of carriage hardware sets with or without SofStop soft-close mechanism
- CarriSnap mounting suspension plate available for the top of the door for mounting and releasing the upper trolley without tools
- SoftStop soft-close mechanisms come in single or twin action for doors weighing up to 176 lb (80 kg), and single action for doors weighing up to 264 lb (120 kg)
- Trim clips are included in the pocket frame sets for easy press-on mounting of door jamb trim
- Features a pivoting bottom guide to ease loading the door into the pocket frame during installation
- Large wheel trolleys with precision ground bearings for smooth running
For basic pocket door kits without soft-close, see the Suggested Products section below for a direct link to CS Cavity Slider Pocket Door Kit.
Ideal for a wide variety of applications in residential, commercial, and institutional projects .
IMPORTANT: For 2 x 6 wall construction, see the CS Cavity Sliders Ultimate Pocket Door System.
