For drawers, right-hand or left-hand doors
Cams included for lipped/overlay construction (straight cam; 1-1/2" extension) or flush construction (formed cam; 1-1/8" extension, 11/32" offset)
For overlay application, the combined thickness of front and frame cannot exceed the cylinder length listed below. To accommodate an overlay construction using a 3/4" front and a 3/4" frame, order the NLC8073 lock and the NLC7014-2C cam
Stop washers provided for both 90 degree or 180 degree cam turns
Key removable in both locked and unlocked positions
Supplied with two keys, trim washer, spur washer (for wood), mounting nut, two cams and two stop washers
Unassembled REMOVACORE versions of this lock are available
Stock Keying is specified on table below:
KA = All (K)eyed (A)like to key number specified, master key will not work on these locks
KD = All (K)eyed (D)ifferent, various lock numbers, master key will not work on these locks
KDMKD = All (K)eyed (D)ifferent and (M)aster (K)eyed, master key will work on these locks
Other key changes available from National Lock via SPECIAL ORDER
Packing: 25 each per box.
Sold In: Both broken and full box quantities. Discount available for full box orders.
DK Hardware Professional Tax Exempt? Net 30? - DK Net Terms
Roll over image to zoom in
Product Features
Product Overview
Related Videos
Reviews
Questions & Answers
CompX National C8075-C346A-14A Disc Tumbler Cam Lock with 1-7/16" Cylinder, 3/4" Mounting Hole Bright Nickel
Item #: C8075-C346A-14A by CompX National
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Finish
Bright Nickel
Cylinder Length
1-7/16"
Application
Doors and Drawers
Keying
Keyed Alike #346
Maximum Material Thickness
1-1/8"
Product Type
Cam Lock
Mount Type
Flush or Lipped/Overlay
Tumbler Type
Disc
Heading
Bright Nickel
Key Number
346
Color/Finish
Bright nickel
Manufacturer Series
C8075
Product Overview
90 degree, 180 degree Cam Turn, Flush or Lipped/Overlay Construction
Each lock comes with two stop washers allowing cam to turn either 90 degree or 180 degree based on applicationFor drawers, right-hand or left-hand doors
Cams included for lipped/overlay construction (straight cam; 1-1/2" extension) or flush construction (formed cam; 1-1/8" extension, 11/32" offset)
For overlay application, the combined thickness of front and frame cannot exceed the cylinder length listed below. To accommodate an overlay construction using a 3/4" front and a 3/4" frame, order the NLC8073 lock and the NLC7014-2C cam
Stop washers provided for both 90 degree or 180 degree cam turns
Key removable in both locked and unlocked positions
Supplied with two keys, trim washer, spur washer (for wood), mounting nut, two cams and two stop washers
Unassembled REMOVACORE versions of this lock are available
Stock Keying is specified on table below:
KA = All (K)eyed (A)like to key number specified, master key will not work on these locks
KD = All (K)eyed (D)ifferent, various lock numbers, master key will not work on these locks
KDMKD = All (K)eyed (D)ifferent and (M)aster (K)eyed, master key will work on these locks
Other key changes available from National Lock via SPECIAL ORDER
Packing: 25 each per box.
Sold In: Both broken and full box quantities. Discount available for full box orders.
