30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Projection
2.8125
Finish
Oil Rubbed Dark Bronze
Grade
ANSI/BHMA Grade 2
Lever Length
4.5000
Backset
2-3/8 Inch, 1 x 2-1/4 Inch, Square Corner
Function
55-Classroom
Door Thickness
1-3/8" - 1-7/8"
Strike
T-Strike, 1-1/8 Inch x 2-3/4 Inch, 1-1/4 Inch Lip, Sq Corner
Bore Size
2.1250
Cylinder Type
Conventional Less Cylinder
Finish Description
Oil Rubbed Dark Bronze
Latch Number
599F92
Strike Number
T-Strike, 1-1/8 Inch x 2-3/4 Inch, 1-1/4 Inch Lip, Sq Corner.
Lever Style
NZD-Newport
Rose/Escutcheon Trim
Round Rose
Product Type
Cylindrical Lock
Series
CL3800 Series
Application
Interior Offices; Storage Closets; Restaurants; Retail Complexes
Warranty
5 year limited
Color Code
613/US10B
Handle Type
Lever
Rose Diameter
3-1/2 Inch
Latch Throw
1/2 Inch
ANSI Function
F84
Strike Type
T-Strike Curved Lip Box
ADA Compliant
YES
Finish Family
Dark Bronze
Door Cross Bore
2.125 Inch
Standards
ANSI/BHMA A156.2; Meets A117.1 Accessibility Code; Covers ANSI/DHI Door Prep A115.18 - 1994 "Spider Cut Out"
Cylinder Type Used
Less Cylinder
Function Description
Deadlocking latch bolt by levers. Outside knob/lever is locked by key in outside lever. Inside knob/lever is always free.
Front Size
1-1/4" x 4-7/8" x 1"
Function Family
Classroom
Strike Lip
1-1/4 Inch
Product Projection
2-13/16 Inch
Strike Material
Brass
Trim Material
Solid Cast Zinc (Lever); Brass (Rose)
Features
Lever Release (TM) for Vandal Resistance; Solid Cast Levers; UL 3-Hour Fire Rating; Independent Lever Return Springs; Through-Bolts on Door for Solid Attachment
Latch Type
Deadlocking
Strike Size
2-3/4" x 1-1/8" x 1-1/4"
Manufacturer Parent
Assa Abloy
Lever Length-Inches
4.50 Inch
Latch Corner
Square
Knob/Lever Size
4-1/2 Inch
Lever Style Family
Straight Return Lever
Sub-Series
CL_Cylindrical_Locks_corbin_russwin_371
An economical, Grade 2 standard-duty lever lockset which provides an outstanding combination of value and performance. It’s the ideal lever lockset for standard commercial applications. When used in conjunction with the CL3300 Series Extra Heavy-Duty Grade 1 and the CL3500 Series Heavy-Duty Grade 1 Cylindrical Lever Locksets, the overall cost of many projects may be reduced without compromising functionality and durability.
Typical applications include:
