Norton CPS7500 693 CloserPlus Spring Arm Adjustable Surface Mount Door Closer with Sex Nuts Black Finish
Item #: CPS7500 693 by Norton
See reviewsSee reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- Closers for interior and exterior doors shall be full rack-and-pinion type with cast aluminum alloy body.
- Closers shall be surface mounted and shall project no more that 2-3/16" (55mm) from the surface of the door.
- Closers shall be non-handed to permit installation on doors of either hand.
- Closer fluid shall contain lubricity and anti-oxidation agents.
- Closer fluid shall maintain stable viscosity to allow door closer to perform in temperatures ranging from extremely high to as low as -40°F.
- Closers shall have multi-size spring power adjustment to permit setting of spring from size 1 through size 6.
- Closers shall have two non-critical valves, hex key adjusted, to independently regulate sweep speed and latch speed.
- Closers shall have backcheck cushioning controlled by a hex key adjusted valve.
- Closers shall have backcheck position controlled by a hex key adjusted valve.
- [Closers shall have adjustable delayed-action closing controlled by a hex key adjustable valve.]
- [Closers shall be highly corrosion resistant and shall have all external body components of aluminum, brass or stainless steel material and all fasteners of stainless steel.]
- Regular arm and top jamb closers shall have a non-hold open shoe permitting 15% ( +/–7-1/2% ) power adjustment.
- Environmental Product Declaration (EPD) certified
Back Check
Adjustable
Package Volume
333.59375
Stop
Spring Stop
Color
Black Painted
Case Width
12.75"
Hand
Non-Handed
Grade
Grade 1
Fire Rated
3 Hours {A}
Special Marks
Fire rated 3 Hours {A}
Cover
Plastic
Degree Swing
85¼ to 110¼
Type
Surface
Application
Closer Plus Spring Arm
Case Length
15.75"
Package Qty
1
Package Height
3.5"
Case Height
7.75"
Mounting Location
Push Side
Package Width
6.25"
Case Volume
1556.296875
Color Code
693
Origin
USA
BAA Qualified
Yes
Mounting Style
Parallel Arm
Base Material
VARIES
Package Length
15.25"
Cold Weather Fluid
Yes
Arm Type
Parallel Arm Heavy Duty
Closer Size
Adj. 1 to 6
Series
7500 Series
Product Overview
Closer Plus Spring Arm Door Closer, Adjustable Size 1-6, Black Painted
The 7500 Series Door Closer offers customers the ideal combination of superior performance, strength and quality. Ideal for interior or exterior doors in facilities that demand reliability. The 7500 Series Door Closers exceed 25 million cycles, have a rack and pinion design with a cast aluminum body and are non-handed. They are standard with separate and independent, latch, sweep and backcheck intensity valves.
Institutional heavy-duty door closer.
The 7500 Series is an institutional Door Closer offers customers the ideal combination of superior performance, strength and quality. Ideal for interior or exterior doors in facilities that demand reliability.
