DEWALT DCN930P1 Cordless Nailer Kit, Battery Included, 20 V, 5 Ah, 55 Nails Magazine, 30 deg Collation
Item #: DCN930P1 by STANLEY BLACK & DECKER INC
UPC #: 885911901628
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- Help minimize time between shots with Active Flywheel technology in rapid sequential mode eliminating ramp-up time between shots
- Show-up and get right to work with this cordless nailer requiring no compressors or hoses
- Track and manage this Chip-Ready™ tool in the TOOL CONNECT™ system
- Take on tough jobs with up to a 3-1/2 in nail capacity
- Limit maintenance delays with field serviceable springs and driver blade
- Hold two strips of nails using an optional extended magazine (DZN920) constructed from high-grade magnesium (magazine sold separately)
- Install up to 530 sq-ft of subflooring per charge and complete up to 100 ft of wall framing per charge
- Finish a wide range of applications with an powerful brushless motor
- Drive nails up to 72% more sub-flush than previous generation
- High-strength magnesium magazine for durability
Battery Voltage
20 V
Warranty
3 Year Limited
Collation Type
Paper Tape
Magazine Capacity
55 Nails
Fastener Size
0.113 to 0.131 in Dia x 2 to 3-1/2 in L
Hazardous Marine
Hazardous transport required
Nomenclature
DCN930P1 FRMNG NAILER KT 30DEG
Collation Angle
30 deg
Magazine Loading
Bottom
Triggering Mode
Bump Sequential
Tool Only/Battery Included
Battery Included
Magazine Type
Strip
Battery Type
Lithium-Ion
Fastener Type
Framing Nail
Height
6.00
Length
15.31
Width
14.81
Hazardous Material
Yes
Country Origin Code
MX
Volts
20 V
Angle
30 deg
Weight
8.65 lb
Power Source
Battery
Certifications
CSA and UL Listed
Case Included
No
Brushless
Yes
Corded or Cordless
Cordless
Defective Code
B
Each Weight
13.220 LB
Firing Method
Bump and Sequential
Kit or Tool Only
Kit (Battery & Charger)
Loading Type
Top
Maximum Fastener Size
3.5"
Minimum Fastener Size
2"
Returnable
Yes
Sub Brand
20V MAX
Velocity
N
Product Type
Framing Nailer
Voltage
20
Motor Type
Brushless
Width (in)
17.1
Length (in)
17.6
Height (in)
7
Weight (lb)
13.2
Collation
Paper
Magazine Angle
30
Battery Amp Hour
5.0
Battery Platform
DEWALT 20V MAX
Type
Nail Gun
Handle Type
Pistol Grip
Maximum Nail Length
3-1/2 in
Minimum Nail Length
2 in
Body Material
Metal
Nom. Width
5.6 in
Nom. Height
13.2 in
Operating Type
Battery
Nom. Length
13.9 in
Cartridge Cap. [Max]
30
Nail Diam [Nom]
0.113 in to 0.131 in
Application
Framing
Color
Yellow
Package Quantity
1
UL Listed
No
Includes
Battery,Charger,Belt Hook and Screw, Hex Wrench,No Mar Tip,Bag
ADA Compliant
No
Number of Batteries Included
1
Firing Mode
Combination
Maximum Fastener Length
3-1/2 in.
Minimum Fastener Length
2 in.
Features
Fastener Collation,Fastener Depth Control
UNSPSC
27112700
MADE IN THE USA
No
Nailer Type
Framing Nailer
Assembled Product Depth
13.9 in.
Assembled Product Height
13.2 in.
Assembled Product Width
5.6 in
GSA Approved
No
AbilityOne
No
TAA/BAA Compliant
Yes
Product Overview
FRAMING NAILER KIT 30DEG 20V
Specifications:
Specifications:
Application: For residential framing, sheathing, subflooring, setting trusses, punchout and deck building
Includes: (1) Nailer (1) DCB205 Battery (1) DCB1104 Charger (1) Belt Hook and Screw (1) No Mar Tip (1) Hex Wrench and (1) Soft Bag
Complete a wide variety of framing jobs with the DeWALT 20 V Max brushless cordless 30 deg paper collated framing nailer kit. Designed to help minimize downtime between shots with an innovative flywheel that stays active for 6 s after the trigger is released, this lightweight cordless nailer removes the need for hoses and compressors. Install up to 530 sq-ft of sublooring per charge and complete up to 100 ft of wall framing per charge with this next-generation tool that delivers powerful performance in a wide range of applications.
