C2000 Curved Lever Keyed Entry Lockset, Oil Rubbed Dark Bronze

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Dexter Commercial C2000CLENTRC613KDC C2000 Curved Lever Keyed Entry Lockset, Oil Rubbed Dark Bronze

Item #: C2000CLENTRC613KDC by Dexter Commercial

UPC #: 043156642953

See reviews See reviews

26 In Stock $82.29 /each

SAVE UP TO 8.23

Buying in bulk

QUICK SHIPPING*Usually ships in 1 business day
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
Large Order Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment

Design

Curved Lever

Strike

ANSI, 1-1/4 Inch x 4-7/8 Inch, 1-1/4 Inch Lip, Square Corner

Function

ENTR-Entry/Office

Backset

2-3/4 Inch

Finish

Oil Rubbed Dark Bronze

Grade

ANSI/BHMA Grade 2

Keyway

Schlage C

Cylinder Type

Conventional Cylinder

Finish Description

Oil Rubbed Dark Bronze

Lever Style

C-Curved

Keyblank Grouping

DEXT-SCHL-C-6-1

Rose/Escutcheon Trim

Round Rose

Product Type

Cylindrical Lock

Door Thickness

1 3/8" - 1 3/4"

Bore Size

2.1250

Latch Type

Deadlatch

ADA Approved

False

Keying Charges

CCAM

Box Length

7.2000

Box Width

6.7000

Box Height

3.6000

Strike Size

1-1/4" x 4-7/8"

Strike Number

30-148

Manufacturer Parent

Allegion

Function Description

Pushing and turning button on inside locks outside knob/lever requiring use of a key until button is manually unlocked.

ANSI Function

F109

Sub-Series

CL_Cylindrical_Locks_dexter_commercial_5

Lever Style Family

Curved Return Lever

ADA Compliant

YES

Front Size

1-1/8" x 2-1/4"

Handle Type

Lever

Door Cross Bore

2.125 Inch

Box Dimensions (L x W x H)

7.2 x 6.7 x 3.6

Function Family

Entry/Entrance/Office

Standards

UL Listed 3-Hour

Color Code

613/US10B

Strike Type

ANSI Curved Lip

Latch Corner

Square

Cylinder Type Used

Conventional

Strike Lip

1-1/4 Inch

Finish Family

Dark Bronze

C2000 SeriesGrade 2 cylindrical locks

Allegion’s newest product line, Dexter Commercial Hardware, provides the locksmith customer with a competitive option for locks, exits, and closers. With over 200 SKUs of Grade 1, Grade 2, and residential grade products, Dexter Commercial Hardware is your solution for basic, cost constrained jobs.

Specifications:
  • Grade 2, UL listed 3 hour
  • 1 3/8" to 1 3/4" door range standard
  • Brass (605) ball knobs come packaged with square-corner beveled latch with 2 3/4" backset and ANSI 1 1/4" x 2 1/4" T-Strike standard.
  • All other functions (except dummy) include 1 1/8" x 2 1/4" square-corner beveled latch with 2 3/4" backset and ANSI 1 1/4" x 4 7/8" curved lip strike (30-148)
  • Accommodates Schlage conventional 6-pin (keyed 6) in Schlage C keyway, keyed different and SFIC cylinders
Function and lever features: PASS:
  • F75 Passage (non-clutching)
PRIV:
  • F76 Privacy (non-clutching)
SDUM:
  • Single dummy (non-clutching)
CL-ENTR:
  • F109 Entry/office (clutching)
ENTR:
  • F109 Entry/office (non-clutching)
CL-CLRM:
  • F84 Classroom(clutching)
CLRM:
  • F84 Classroom (non-clutching)
CL-STRM:
  • Storeroom (clutching)
STRM:
  • Storeroom (non-clutching)
Designs:
  • Regular lever
  • Curved lever
  • Ball knob
Finishes:
  • 6051
  • 613
  • 6262
  • 6302
  • 1 605 finish not available on Curved lever design.
  • 2 Use 626 finish when ordering lever designs and 630 finish for Ball design.
