Dexter Commercial C2000CLENTRR613KDC C2000 Curved Lever Keyed Entry Lockset, Oil Rubbed Dark Bronze
Item #: C2000CLENTRR613KDC by Dexter Commercial
UPC #: 043156642915
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Finish
Oil Rubbed Dark Bronze
Backset
2-3/4 Inch
Function
ENTR-Entry/Office
Strike
ANSI, 1-1/4 Inch x 4-7/8 Inch, 1-1/4 Inch Lip, Square Corner
Design
Regular Lever
Grade
ANSI/BHMA Grade 2
Keyway
Schlage C
Cylinder Type
Conventional Cylinder
Finish Description
Oil Rubbed Dark Bronze
Lever Style
R-Regular
Keyblank Grouping
DEXT-SCHL-C-6-1
Rose/Escutcheon Trim
Round Rose
Product Type
Cylindrical Lock
Projection
2.5000
Door Thickness
1 3/8" - 1 3/4"
Bore Size
2.1250
Latch Type
Deadlatch
ADA Approved
False
Keying Charges
CCAM
Box Length
7.2000
Box Width
6.7000
Box Height
3.6000
Color Code
613/US10B
Handle Type
Lever
ANSI Function
F109
Strike Number
30-148
Strike Type
ANSI Curved Lip
ADA Compliant
YES
Finish Family
Dark Bronze
Door Cross Bore
2.125 Inch
Standards
UL Listed 3-Hour
Cylinder Type Used
Conventional
Function Description
Pushing and turning button on inside locks outside knob/lever requiring use of a key until button is manually unlocked.
Front Size
1-1/8" x 2-1/4"
Function Family
Entry/Entrance/Office
Strike Lip
1-1/4 Inch
Product Projection
2-1/2 Inch
Manufacturer Parent
Allegion
Latch Corner
Square
Box Dimensions (L x W x H)
7.2 x 6.7 x 3.6
Lever Style Family
Straight Return Lever
Sub-Series
CL_Cylindrical_Locks_dexter_commercial_7
Strike Size
1-1/4" x 4-7/8"
Allegion’s newest product line, Dexter Commercial Hardware, provides the locksmith customer with a competitive option for locks, exits, and closers. With over 200 SKUs of Grade 1, Grade 2, and residential grade products, Dexter Commercial Hardware is your solution for basic, cost constrained jobs.
Specifications:- Grade 2, UL listed 3 hour
- 1 3/8" to 1 3/4" door range standard
- Brass (605) ball knobs come packaged with square-corner beveled latch with 2 3/4" backset and ANSI 1 1/4" x 2 1/4" T-Strike standard.
- All other functions (except dummy) include 1 1/8" x 2 1/4" square-corner beveled latch with 2 3/4" backset and ANSI 1 1/4" x 4 7/8" curved lip strike (30-148)
- Accommodates Schlage conventional 6-pin (keyed 6) in Schlage C keyway, keyed different and SFIC cylinders
- F75 Passage (non-clutching)
- F76 Privacy (non-clutching)
- Single dummy (non-clutching)
- F109 Entry/office (clutching)
- F109 Entry/office (non-clutching)
- F84 Classroom(clutching)
- F84 Classroom (non-clutching)
- Storeroom (clutching)
- Storeroom (non-clutching)
- Regular lever
- Curved lever
- Ball knob
- 6051
- 613
- 6262
- 6302
- 1 605 finish not available on Curved lever design.
- 2 Use 626 finish when ordering lever designs and 630 finish for Ball design.
