Securitron DK-12 Digital Keypad System with Illuminated Keys Single Gang Satin Stainless Steel Finish
Item #: DK-12 by SECURITRON
See reviewsSee reviews
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See How Watch Now
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
- Single Gang, Stainless Steel Plate with Low Voltage Mounting Ring
- 12 Key Illuminated 3x4 Keypad
- True 10 Digit Operation, Plus * and # Keys
- 99 User Code Capability
- MagnaCare, The Best Warranty in the Industry, Lifetime Replacement, No Fault, No Questions Asked
Finish
Satin Stainless Steel
Package Volume
0
Product Width
2.75"
Burglar Rated
No
Fire Rated
No
Restrictions
None
Product Height
0.156"
Package Qty
1
Plastic Color
Black
Color Code
630/US32D
Origin
USA
BAA Qualified
Yes
Product Length
4.5"
Base Material
Stainless Steel
Product Type
Keypads
Voltage
12V DC, 24V DC
Alternate Part Number-1
146886
Mounting
Flush Mount
Reader Style
Keypad
Product Depth
5-3/4 Inch
Manufacturer Parent
Assa Abloy
Finish Description
Satin Stainless Steel
Function
Digital Keypad
Sub-Series
DK-12
Contact Ratings
5A at 30 V
ADA Compliant
No
Operating Temperature
-10 to 140°F
input type
REX
Number of users
99 Inch (8 Foot 3 Inch)
Features
Audible Keystroke Echo; Stainless Steel Backplate; One Piece Digital Keypad Specifically Designed for Control of Electric Locks
Indoor or Outdoor Use
Indoor
Access Modes
Keypad
Series
Parts/Accessories
Product Overview
Single Gang Digital Keypad, 99 Users
The DK-12 standalone keypad and controller is ideal for lower security requirements such as traffic control. Easy to install and easy to program, the one-piece DK-12 supports 99 user codes, including Passage mode and Lockout mode. Single gang, stainless steel plate with low voltage mounting ring. 12 key illuminated 3x4 keypad. True 10-digit operation (10 digits plus * and # keys). Configurable audible keystroke echo. Red, green and yellow LEDs for status and programming feedback. Fail secure or fail safe-capable. Accepts 12V or 24 VAC or DC current. 5A SPDT timed, control relay output. Request to exit (REX) input.
