Milling Insert: JC5040, Solid Carbide TiAlN

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Dijet SWB2100HMEJC504 Milling Insert: JC5040, Solid Carbide TiAlN

Item #: SWB2100HMEJC504 by Dijet

See reviewsSee reviews
See reviews summary
Use Code: SAVEBIG2025 for Extra 10% Off
HURRY! Low in stock

$34.42

/each
SAVE UP TO 3.44
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 3 units available
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Volume Pricing

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
Features

Iso Code

SWB2100HMEJC504

Corner Radius (mm)

12.70

Inscribed Circle (mm)

18.49

Thickness Range (Decimal Inch)

0.1500 to 0.1750

Length Range (Decimal Inch)

0.7000 to 0.9000

Inscribed Circle Range (Decimal Inch)

0.7000 to 1.0000

Manufacturer Grade

JC5040

Cutting Edge Effective Length (Decimal Inch)

0.7280

Hole Diameter (Decimal Inch)

0.5000

Insert Size Code

2100HME

Insert Style

SWB

Chip Breaker

JC

Insert Shape

Oval

Corner Radius (Inch)

1/2

Inscribed Circle (Decimal Inch)

0.7280

Insert Hand

Neutral

Insert Holding Method

Screw

Coating Classification

PVD

Width (mm - 2 Decimals)

12.37

Width (Decimal Inch - 4 Decimals)

0.4870

Vendor Drop Ship

N

Thickness (Decimal Inch - 4 Decimals)

0.1500

Primary Workpiece Material

Universal

Manufacturers Catalog Number

SWB2100HMEJC504

Length (Decimal Inch - 4 Decimals)

0.7280

Corner Radius (Decimal Inch)

0.5000

Coating/Finish

TiAlN

Coating Process

PVD

Series

SWB

Insert Material

Solid Carbide

Thickness (mm)

3.81

ANSI Code

SWB2100HMEJC504

Length (mm)

18.49

Material Application

Universal

Product Overview
Milling Insert: JC5040, Solid Carbide Coated, 0.15" Thick, 0.487" Wide
