Diversitech CP-22-230 CP Series 12 in. x 6 in. x 6-3/4 in. 230-Volt Condensate Removal Pump
Item #: CP-22-230 by DiversiTech
UPC #: 095247092994
In Stock $181.95 /each
Buying in bulk
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Color
Black, Red
Product Width (in.)
6
Inlet Diameter (in.)
0.375
Certifications and Listings
UL Listed
Product Height (in.)
6.75
Pack Size
1
Product Depth (in.)
12.0
Cord Length (ft.)
6
Warranty
Standard
Manufacturer Warranty
Standard
UNSPSC
40151500
A full featured pump suitable for use with condensate from high efficiency condensing furnaces and boilers which produce acidic condensate. It has 22 ft. of lift compared to the typical 20 ft. Features include vibration dampening feet and motor mounts, metal hang tabs, 4-inlet holes, a clear indicator display, a float switch and check valve.
- Elastomeric motor mounting gasket dampens vibration
- Red, yellow, and green indicator lights show the pump status; the green shows the power applied to the pump, yellow shows the pump is running, and red is for high level alarm
- Rubber feet that support the pump help to dampen vibration which reduces noise
- 4-inlet versus 2 or 3 on other pumps provide the greatest installation versatility, inlet holes have a reinforced wall for durability
- Features a removable check valve which allows for hassle free cleaning
- 1/4 in. quick connect terminals provide easy connection to the built-in overflow switch
- 2-terminals are provided allowing the installer flexibility to connect the air handler shut-down
- Switch features SPDT isolated contacts ready for connection to building automation systems
- Pump comes equipped with shatterproof stainless steel hang tabs which have hole-and-slot design for easy mounting
- Tabs are located on convenient 8 in. centers
