Kaba Access E1502-605-41 E-Plex 1500 Deadbolt With Key Override, Electronic Pushbutton Deadbolt, 100 Access Codes, Bright Polished Brass Finish
Item #: E1502-605-41 by Ilco
Brand: Kaba Access
See reviewsSee reviews
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
- Constructed with a solid brass cast exterior housing and metal pushbuttons, featuring a bright polished brass finish.
- Adjustable backset of 2-3/8" or 2-3/4" and fits door thicknesses from 1-3/8" to 2" with a 4" minimum stile width.
- Electronic deadbolt platform with 100 access codes and 1,000 audit event memory, including mechanical key override tracking.
- Operates on three AA alkaline batteries with no wiring required to or through the door for installation.
- ANSI/BHMA Grade 2 certified and UL 10C fire-rated for doors up to three hours, suitable for various security applications.
- Designed for exterior and interior use in temperatures from -31 F to 151 F, meeting ANSI A156.25 corrosion standards.
- Includes lock assembly, installation manual, template, quick reference guide, operations manual, and required hardware.
Package Qty
1
Lock Platform
Deadbolt Lock
Minimum Stile Width
4 Inch
Manufacturer Parent
DormaKaba
Locking Device
Deadbolt
Finish Description
Bright Polished Brass
Function
Electronic Pushbutton Deadbolt
Grade
ANSI/BHMA Grade 2
Sub-Series
E1502-41
Fire Rated
Yes
Door Preparation
ASA 161
Operating Temperature
Outside and inside housing; -31 °F to 151 °F (-35 °C to 66 °C)
Cylinder Type
Conventional
Key Override Core Type
1539 6-pin cylinder
Programming Method
Keypad
Battery Used
Three AA Alkaline
Number of Access Codes
100
Door Thickness
1-3/8 to 2 Inch
Product Type
Electronic Deadbolt
Features
Requires No Wiring to or Through the Door; Multiple Users 100 Codes; The Most Recent 1000 Lock Events are Recorded in Memory; Including the Use of Mechanical Key Override; Software is Required to View Audit Events; Lock is Easily Programmed
Color Code
605/US3
Audit Buffer
The most recent 1,000 lock Events are recorded in memory, including the use of mechanical key override. Software is required to view audit Events.
Backset
2-3/8 Inch or 2-3/4 Inch
Warranty
2-year warranty from date of installation; built-in warranty counter in memory
Keyway
Kaba Schlage C
Series
E1500 Series
Operation
PIN access, Passage—can be toggled on/off or can be pre-programmed to re-lock after a certain number of hours, Lockout
Power
Three AA Alkaline Batteries
Included Components
Lock Assembly, Installation Manual, Template, Quick Reference Guide, Operations Manual, and Required Hardware
Onboard Programming
Lock is easily programmed via keypad without removing lock from the door or with optional Microsoft Excel-based software
Finish Family
Polished Brass
Product Overview
The E-Plex 1500 Deadbolt with Key Override is an electronic pushbutton deadbolt designed for access control on wood or metal doors. This lockset features a solid brass cast exterior housing with metal pushbuttons and is suitable for doors with a thickness ranging from 1-3/8" to 2". It is built to ANSI/BHMA Grade 2 standards and meets UL 10C requirements for fire-rated doors up to three hours. The lock operates on three AA alkaline batteries and requires no wiring to or through the door. It supports 100 access codes and records the most recent 1,000 lock events in memory, including mechanical key override usage. Programming is performed via the keypad or optional software. The deadbolt includes an adjustable backset of 2-3/8" or 2-3/4" and requires a minimum stile width of 4". It is designed for operation in temperatures ranging from -31 F to 151 F. The unit includes a 1539 6-pin conventional cylinder for key override. The finish is bright polished brass.
