Euro Limited GENEL200 Concealed European Hinge Mounting Plate Drilling Tool
Item #: GENEL200 by Euro Limited
See reviewsSee reviews
Use Code: SAVEBIG2025 for Extra 10% Off
30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
Features
Type of Jig
For Mounting Plate Installation
Finish
Anodized Aluminum
Material
Plastic, Steel, Ceramic Nylon
Depth
1.5 in
Length
28.75 in
Width
4 in
Product Overview
This jig quickly and accurately locates and sets drilling holes for concealed hinge mounting plates on the inside of a cabinet wall. Useful with all brands of European hinges and mounting plates, regardless of the cup size. Works for overlay and inset mounting plate conditions, setting mounting plates for doors up to 50" tall. Extruded aluminum rails, lexan-polycarbonate templates, aluminum bushings.
