Features
- Key it Yourself: Lock is rekeyable by using the included learn tool in less than 30 seconds without removing the lock from the door.
- Bumpguard: Patented side locking bar technology replaces a traditions pin & tumbler design to protect against lock bumping.
- Drill Resistance: Cylinder uses two steel balls inserted into the front of the key face to resist attack from drilling.
- Door prep: Crossbore 2-1/8" or 1-1/2" Edge Bore 1"
- Door thickness: 1-3/8"-1-3/4" doors standard.
- Cylinder: SmartKey 5-pin
- Smart Key Cylinders are 5-pin, and will not key alike to 6-pin cylinders.
- Includes a Square Corner Faceplate
- Bolt: 1" throw Nickel plated steel.
- Fully adjustable latch & deadbolt to fit standard gates
- ANSI/BHMA Grade 2
- Lifetime mechanical and finish warranty
Product Class
Residential
Theme
Transitional
Shape
Round
Application
Gate Hardware
Backset
2-3/8"
Function
Double Cylinder
Door Thickness
1-1/2", 1-3/4", 1-3/8", 1-5/8"
Collection
Gatelatch
ADA
No
BHMA Certification
Grade 2
Cross Bore
2-1/8"
Cylinder
SmartKey 5 Pin
SmartKey
Yes
Series
Signature Series
Latch Faceplate
Drive-In, Round Corner, Square Corner
No Of Pins
5 Pin Cylinder
No of inners
1
Latch Faceplate Dimension
1" x 2-1/4"
Finish code
US26D
Cross Bore Size
2-1/8" Bore
Strike Dimension
1-1/8" x 2-3/4"
Hazardous Material
No
Door Range
1-3/8" to 1-3/4"
Manufacturer Warranty
Limited Lifetime Mechanical and Finish Warranty
Strike
3028 T Strike
Keyway
Kwikset SmartKey
Handing
Reversible
Material
Zinc
Finish
Satin Chrome
Product Overview
Double Cylinder Function: The deadbolt is thrown and retracted by a key from either side. As you will not be able to unlock this from the inside without a key, please check your local fire code to ensure this is allowed before purchasing.
