Features
- Lower bound
Material
Aluminum Alloy
Trigger Mechanism
Short path triggering
Graduation
25.1.1900
Standard
DIN 3120 - B 25 ISO 1174
Torque Wrench Type
EK
1000 v insulated
31.12.1899
Calibration length
1473 mm
Customs tariff number
82041100
Distance housing - square drive
30 mm
Drive connector square (male)
1" | 25 mm
Drive type/drive
Single square
Fixed setting
31.12.1899
Head height 1 [mm]
40 mm
Length extension tube
925 mm
Net weight [kg]
10,8 kg
Precision +/-
+/- 3 %
Range of application
Assembly Series assembly Production Maintenance and repair
Reach registration available
31.12.1899
Scale division [n-m]
25 N·m
Storage/content
Box
Target groups
Automotive Industry Construction and commercial vehicles Military Energy Mechanical engineering Workshop Utilities Service Agriculture Oil & Gas
Test certificate
DIN EN ISO 6789-2:2017
Tightening direction
Right
Torque (max.) [n·m]
1500 N·m
Torque (min.) [n·m]
600 N·m
Torque range (min./max.) [lbf·ft]
-
Torque range (min./max.) [n·m]
600 N·m - 1500 N·m
Total height [mm]
71 mm
Total length [mm]
932 mm
Total width [mm]
60 mm
Vde certified
31.12.1899
Width of head 1 [mm]
60,0 mm
Product Overview
Use: Controlled screw tightening in the range from 600 - 1500 N m, For use in almost all industrial manufacturing areas, Features: Classified according to DIN EN ISO 6789-2:2017 Type II Class A, incl. traceable test certificate, calibrated to a maximum permissible deviation of +/- 3 % and thus more precise than the +/- 4 % required by the standard, 1" square drive with pin-locking mechanism DIN 3120 - B 25, ISO 1174, Automatic short-path actuation with tactile impulse and audible signal, Single scale with a scale graduation of 25 N m, Technical advantage/Function: Lightweight yet robust (as the housing is made of an aluminum alloy) and resilient, very workshop-friendly, No inaccuracies whether used with both hands or held away from the handle (as for standard torque wrenches), Both the square drive and fulcrum are on an axis which ensures a high degree of user safety; can be extended to reduce the user's working load., Double-lever mechanism for maximum cutting performance, Forged lever chain from our group own quality forge, Maximum precision even when subjected to extreme continuous use, Long life cycles and tool lives, Easy operation - fast and safe torque tightening
Parts list: Extension tube
8564-92
Parts list: Extension tube
8564-92
