Features
- Lower bound
Screws Included
31.12.1899
Number of Arms
3.1.1900
Graduation
31.12.1899
Spindle Thread Size
G 1/2 x 210
1000 v insulated
31.12.1899
3d data available
31.12.1899
Anti-slip device on the spindle
31.12.1899
Can be retrofitted with hydraulic spindle
1.1.1900
Clamping bracket available
31.12.1899
Clamping width (max.) external pulling [mm]
200 mm
Clamping width a2 (max.) internal pulling [mm]
260 mm
Clamping width a2 (min.) internal pulling [mm]
100 mm
Customs tariff number
82055980
Hook brake available
1.1.1900
Hook can be moved parallel
31.12.1899
Hydraulic spindle optional
1.06/HSP1
Net weight [kg]
3,7 kg
Quick release lever available
31.12.1899
Reach registration available
31.12.1899
Reversible arms available
1.1.1900
Spindle anti-slip device
31.12.1899
Thickness of hooked foot at tip
3,5 mm
Tractive force (max.) [t]
5.1.1900
Usable clamping reach [mm]
150 mm
Usable depth of hooked foot d2 [mm]
24 mm
Vde certified
31.12.1899
Width across flats [mm]
22 mm
Width of hooked foot [mm]
30 mm
Product Overview
Rigid legs forged from one piece, Leg brake - prevents unintentional leg slipping. The leg can be slid along the cross-beam at the push of a button, By reversing the legs, this tool can be used as an internal or external puller, Extra or replacement legs increase versatility, Upgradeable with hydraulic spindle (see table), Upgradeable with hydraulic spindle (see table)
