DVV-540RS Torque Multiplier DREMOPLUS ALU 54000 Nm

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Gedore 15.2.9164 DVV-540RS Torque Multiplier DREMOPLUS ALU 54000 Nm

Item #: 15.2.9164 by Gedore

Brand: Gedore

UPC #: 4010886934425

See reviewsSee reviews
See reviews summary

$35,566.77

41,108.15 /each
SAVE UP TO 3556.68
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Custom Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Lower bound

1000 v insulated

31.12.1899

Backflow protection

1.1.1900

Customs tariff number

82041100

Drive connector square (male)

3/4"

Drive connector square female (metric)

6,3 mm

Drive connector square female [inch]

3/4"

Eingangskraft [n·m]

380 N·m

Input force [lbf·ft]

280 lbf·ft

Multiplication at the ratio

31.12.1899

Net weight [kg]

64,6 kg

Output square

2.1/2

Output square (inch)

2.1/2

Output square (metric)

63 mm

Output torque (max.) [lbf-ft]

1.6.2010

Output torque (max.) [n-m]

4.11.2047

Reach registration available

31.12.1899

Total height without reaction arm

18.2.1901

Total length [mm]

230 mm

Total width without reaction arm

26.9.1900

Vde certified

31.12.1899

Version reaction arm

without

Version/execution

With fixture for welding on a reaction arm

Product Overview
Especially suitable for: Heavy industry, Oil industry, Petrochemicals, Features: Mechanical hand torque multiplier for controlled screw tightening and unloosening screw connections, With a three-stage planet gear, High-performance aluminum housing, Reaction arm of chrome-vanadium steel, Model with transmission ratio 1:175, With anti-wind-up ratchet (RS), With non-destructive overload protection "Slipper" to protect the gearbox, right and left hand, With fixture for welding on a reaction arm (optional), Guaranteed accuracy: Better than +/- 3 % tolerance, To operate with a suitable torque wrench, 1 actuating arm hexagonal 27 mm, 354 mm, No. E-28 LRZ-27, Output square with hole for Impact sockets with locking pin and ring
Parts list: Torque multiplier DREMOPLUS ALU
Delivery in stable box on pallet
Adjustment table
Detailed technical information is available on request
