Features
- Lower bound
Material
Aluminum Alloy
Trigger Mechanism
Short path triggering
1000 v insulated
31.12.1899
Customs tariff number
82041100
Distance housing - square drive
62,5 mm
Drive connector square (male)
1/4" | 6,3 mm
Drive type/drive
Single square rigid
Fixed setting
1.1.1900
Fixed setting value
9 N·m
Net weight [kg]
0,241 kg
Precision +/-
+/- 6 %
Range of application
Assembly Series assembly Production
Reach registration available
31.12.1899
Target groups
Automotive Electronics industry Precision mechanics Military Energy Mechanical engineering Control cabinet construction
Tightening direction
Right
Torque (max.) [n·m]
9 N·m
Torque range (min./max.) [lbf·ft]
-
Torque range (min./max.) [n·m]
-9 N·m
Total height [mm]
22 mm
Total length [mm]
100 mm
Total width [mm]
125 mm
Vde certified
31.12.1899
Product Overview
Use: Power-saving application for torques which are usually in the range of torque screwdrivers, E.g. securing modules on solar power systems, tool supports etc.; wherever the torques are too large for classic torque screwdrivers, Features: Torque wrench series with 8 pre-set models for serial production, For controlled directional tightening, Working accuracy acc. to DIN EN ISO 6789-2:2017 Typ II Class E (+/- 6 %), Lightweight and robust - housing made of a high-quality aluminum alloy, With certificate acc. to DIN EN ISO 6789-2:2017, traceable via in-house DAkkS laboratory to national standards, Special ranges are available on request
