1.07/4A1-B-HSP3 Universal puller, 3-arm, hydraulic, 580x140mm

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Gedore 19.4.8872 1.07/4A1-B-HSP3 Universal puller, 3-arm, hydraulic, 580x140mm

Item #: 19.4.8872 by Gedore

Brand: Gedore

UPC #: 4010886944202

See reviewsSee reviews
See reviews summary

$3,945.43

4,560.13 /each
SAVE UP TO 394.54
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Custom Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Lower bound

Clamping bracket available

31.12.1899

Clamping width (max.) external pulling [mm]

580 mm

Clamping width (min.) external pulling [mm]

150 mm

Clamping width a2 (max.) internal pulling [mm]

640 mm

Clamping width a2 (min.) internal pulling [mm]

270 mm

Customs tariff number

82055980

Hook brake available

1.1.1900

Hook can be moved parallel

31.12.1899

Hydraulic spindle

1.06/HSP3

Net weight [kg]

23,1 kg

Quick release lever available

31.12.1899

Reach registration available

31.12.1899

Reversible arms available

1.1.1900

Spindle anti-slip device

1.1.1900

Thickness of hooked foot at tip

6,5 mm

Total length [mm]

137 mm

Tractive force (max.) [n]

25,0 N

Tractive force (max.) [t]

10.1.1900

Usable clamping reach [mm]

140 mm

Usable depth of hooked foot d2 [mm]

28 mm

Vde certified

31.12.1899

Width of hooked foot [mm]

36 mm

Can be retrofitted with hydraulic spindle

31.12.1899

Anti-slip device on the spindle

31.12.1899

3d data available

31.12.1899

1000 v insulated

31.12.1899

Graduation

31.12.1899

Screws Included

31.12.1899

Product Overview
It is also suitable for removing heavy, multistage V-belt pulley wheels, flywheels, gear wheels, etc., Pins are used to lock the arms at 120 degrees to each other on the hub, Rigid legs forged from one piece, Leg brake - prevents unintentional leg slipping. The leg can be slid along the cross-beam at the push of a button, By reversing the legs, this tool can be used as an internal or external puller, This puller may also be used with the hydraulic aid no. 1.50 without requiring any reduction bushing, On request, this puller is also available with further legs and extendable up to 6 arms, The pressure piece can be replaced by a tip and lengthened, as required., The small pressure spindle is secured with an unscrewing lock to stop any accidental withdrawal., Also available with standard spindle - Model 1.07/4-B, Controlled removal is only guaranteed when using a torque wrench
