Features
- Lower bound
Vde certified
31.12.1899
Total length [mm]
670 mm
Torque range (min./max.) [n·m]
10 N·m - 120 N·m
Torque range (min./max.) [lbf·ft]
7,4 lbf·ft - 88,5 lbf·ft
Torque (min.) [n·m]
10 N·m
Torque (min.) [lbf·ft]
7,4 lbf·ft
Torque (max.) [n·m]
120 N·m
Torque (max.) [lbf·ft]
88,5 lbf·ft
Tightening direction
Left and right
Target groups
Automotive Industry Construction and commercial vehicles Military Energy Mechanical engineering Workshop Utilities Service Railway Agriculture Oil & Gas
Reach registration available
31.12.1899
Range of application
Assembly Series assembly Production Quality control Maintenance and repair
Precision +/-
+/- 1 %
Net weight [kg]
1,2 kg
Measuring accuracy angle of rotation
±1% , min. ±1° auf 360° bei mind. 4°/sec.
Graphic display
31.12.1899
Fixed setting
31.12.1899
Evaluation software
31.12.1899
Epa-/esd-model
31.12.1899
Drive type/drive
Rectangular cavity
Drive connector square (male)
1/2" | 12,5 mm
Drive connector rectangular
9 x 12 mm
Customs tariff number
82041100
1000 v insulated
31.12.1899
Measurement accuracy
± 1% Toleranz vom Ablesewert, ± 1 Digit
Interface
USB
Product Overview
Use: For everyday requirements in installation and torque control, For use in all areas of manufacturing and development, Features: Microprocessor-controlled, electronic torque wrench, For controlled bi-directional tightening, Acc. to DIN EN ISO 6789, traceable to national standards, Robust workshop construction, Wide measuring range in N m, can be switched to cN m, lbf ft or lbf in, With 1/2" reversible ratchet. The ratchet is exchangeable, providing the option of using a 9x12 mm (TT3H 120) or 14x18 mm (TT3H 350) square socket, Characteristics: Torque and torque angle measure, 4 different measuring modes, 5 parameters storable, USB interface for data exchange, 2000 storage places, Measurement accuracy torque +/- 1 %, +/- 1 digit, Measurement accuracy torque angle +/- 1 %, but min. +/- 1 degree on 360 degree with min. 4 degree/sec, Different depth gauges for end fittings programmable, Simple to operate with easy to understand Icon-menu navigation and 4 functional keys, Clearly readable, illuminated LCD display, Resolution torque: 0.1 N m, Resolution torque angle: 0.1 degree, PC-software easy to operate for uncomplicated programming and documentation of data, Data can be transfered to MS Excel , Keyboard lock, Operation with standard Mignon AA or optional with rechargeable-battery (NiMH), Visual signal: 3x LED (yellow, green, red), Acoustic signal: buzzer, T V S D approved, CE and RoHS
