Features
- Lower bound
1000 v insulated
31.12.1899
Clamping bracket available
31.12.1899
Customs tariff number
82055980
Net weight [kg]
7,6 kg
Reach registration available
31.12.1899
Reversible arms available
31.12.1899
Vde certified
31.12.1899
Product Overview
Using the GEDORE ball bearing extractor, the removal of shaft-mounted ball bearings in a housing is now possible without any problems, The design allows a PLUS in effectiveness and productivity through a maximum of functionality in combination with simplified handling, This tool is easy to use: The legs are fixed in the slot, The self-locking arrangement means that the force applied is 100 % utilised, Secure at all times against slipping off - and a straight pulling force for precise working, Suitable for more than 40 standard ball bearings up to 6311, 1.92/2 for bearings: 6011-6012, 6206-6212, 6305-6311, 6403-6407
Parts list: Bearing hook head size
60001.92/10192/1-7
60011.92/10192/1-4
60021.92/10192/1-3
60031.92/10192/1-4
60041.92/30192/1-3
60051.92/30192/1-3
60061.92/30192/1-3
60071.92/40192/1-3
60081.92/40192/1-3
60091.92/40192/1-3
60101.92/40192/1-3
62001.92/10192/1-4
62011.92/20192/1-7
62021.92/20192/1-4
62031.92/30192/1-4
62041.92/40192/1-4
62051.92/40192/1-3
63001.92/30192/1-3
63011.92/40192/1-3
63021.92/40192/1-7
63031.92/40192/1-7
63041.92/40192/1-7
60111.92/50192/2-3
60121.92/50192/2-3
62061.92/50192/2-3
62071.92/50192/2-3
62081.92/60192/2-3
62091.92/60192/2-3
62101.92/60192/2-3
62111.92/60192/2-3
62121.92/70192/2-3
63051.92/60192/2-7
63061.92/60192/2-4
63071.92/60192/2-4
63081.92/70192/2-4
63091.92/70192/2-4
6310**1.92/70192/2-4
6311***1.92/70192/2-4
64031.92/60192/2-3
64041.92/70192/2-3
64051.92/70192/2-7
64061.92/70192/2-7
6407*1.92/60192/2-7
Content Sentence
1.92/1 and
1.92/2
* with support ring 6309
** with support ring 6310
*** with support ring 6311
