Features
- Lower bound
Trigger Mechanism
Long travel triggering
1000 v insulated
31.12.1899
Customs tariff number
82041100
Depth gauge [metric]
32,0 mm
Drive connector pin
16 mm
Drive connector square (male)
3/8"
Drive type/drive
Drive pin
Epa-/esd-model
31.12.1899
Fixed setting
31.12.1899
Graduation [lbf·ft]
125 lbf·ft
Net weight [kg]
1,14 kg
Range of application
Assembly Series assembly Production Quality control Repair and maintenance Maintenance and repair Testing and trial departments
Reach registration available
31.12.1899
Target groups
Automotive Industry Military Mechanical engineering Service
Test certificate
DIN EN ISO 6789-2:2017
Tightening direction
Left and right
Torque (max.) [lbf·ft]
37 lbf·ft
Torque (min.) [lbf·ft]
7 lbf·ft
Total length [mm]
365 mm
Vde certified
31.12.1899
Product Overview
Type ATB 25 lbf ft to ATB 100 lbf ft with 16 mm pin, Incl. Ratchets (1/4", 3/8" or 1/2" depending on the version), With micrometre scale, which allows quick and precise adjustment of the desired value, With adjuster lock that prevents accidental adjustment during use, Working accuracy: +/- 4 % tolerance of set torque, Breaking of the handgrip by 20 degree when the pre-set torque value is achieved makes over-tightening unlikely, Classified according to DIN EN ISO 6789 Type II Class A., Available in N.m, lbf.in or lbf.ft versions, Tool can be kept accurate and up to date with our Calibration service.
