Gedore 24.11.7014 1.04/HP3A Universal puller, 2-arm, 350x200 mm, HIGH POWER

Item #: 24.11.7014 by Gedore

Brand: Gedore

UPC #: 4036976113525

See reviewsSee reviews
See reviews summary

$837.53

/each
SAVE UP TO 83.75
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Custom Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Lower bound

Width of hooked foot [mm]

36 mm

Width across flats [mm]

27 mm

Version/execution

2-arm pattern

Vde certified

31.12.1899

Usable depth of hooked foot d2 [mm]

28 mm

Usable clamping reach [mm]

200 mm

Tractive force (max.) [t]

15.1.1900

Thickness of hooked foot at tip

6,5 mm

Spindle width across flats

27 mm

Spindle thrust piece type

Kugel & Spitze

Spindle thread length (usable) [mm].

280 mm

Spindle surface coating

Nitro-carburated

Spindle holder

G3/4"

Spindle anti-slip device

31.12.1899

Reversible arms available

1.1.1900

Reach registration available

31.12.1899

Quick release lever available

1.1.1900

Net weight [kg]

7,7 kg

Load of the entire puller (max.) [t]

15 t

Hydraulic spindle optional

1.06/HSP2

Hook can be moved parallel

1.1.1900

Hook brake available

31.12.1899

Exchangeable spindle tip

1.1.1900

Customs tariff number

82055980

Clamping width a2 (min.) internal pulling [mm]

150 mm

Clamping width a2 (max.) internal pulling [mm]

420 mm

Clamping width (max.) external pulling [mm]

350 mm

Clamping bracket available

31.12.1899

Can be retrofitted with hydraulic spindle

1.1.1900

Anti-slip device on the spindle

31.12.1899

3d data available

31.12.1899

1000 v insulated

31.12.1899

Spindle Thread Size

G3/4x280mm

Graduation

x

Use

For removing drive pulleys, wheels, ball bearings etc.

Number of Arms

2.1.1900

Screws Included

31.12.1899

Number Of Hooks

2.1.1900

Product Overview
Strong drop forged pattern, By reversing the legs, this tool can be used as an internal or external puller, Scale for uniform adjustment of the puller legs. Allows centred pulling, with optimised application of force, even when extremely high pulling forces are required, Integral legs, with quick-release, Spindle with replaceable ball and tip, Spindle thermo-chemically hardened, Upgradeable with hydraulic spindle (see table), Upgradeable with hydraulic spindle
