Features
- Lower bound
Material
Glass fibre reinforced high-tech polyamide
Trigger Mechanism
Short path triggering
1000 v insulated
31.12.1899
Calibration length
130 mm
Customs tariff number
82041100
Distance housing - square drive
14,5 mm
Drive connector square (male)
1/4" | 6,3 mm
Drive type/drive
Single square rigid
Fixed setting
31.12.1899
Graduation [lbf·in]
5 lbf·in
Head height 1 [mm]
28 mm
Net weight [kg]
0,55 kg
Precision +/-
+/- 3 %
Range of application
Assembly Series assembly Production Maintenance and repair
Reach registration available
31.12.1899
Scale division [n-m]
5 N·m
Target groups
Automotive Electronics industry Precision mechanics Military Energy Mechanical engineering Workshop Service Agriculture Control cabinet construction
Test certificate
DIN EN ISO 6789-2:2017
Tightening direction
Right
Torque (max.) [lbf·ft]
106 lbf·ft
Torque (max.) [lbf·in]
22,5 lbf·in
Torque (max.) [n·m]
12 N·m
Torque (min.) [lbf·ft]
22,5 lbf·ft
Torque (min.) [lbf·in]
106 lbf·in
Torque (min.) [n·m]
2,5 N·m
Torque range (min./max.) [lbf·ft]
22,5 lbf·ft - 106 lbf·ft
Torque range (min./max.) [lbf·in]
22,5 lbf·in - 106 lbf·in
Torque range (min./max.) [n·m]
2,5 N·m - 12 N·m
Total height [mm]
31,5 mm
Total length [mm]
211 mm
Total width [mm]
31,5 mm
Vde certified
31.12.1899
Vernier nm
0,05 N·m
Width of head 1 [mm]
28,5 mm
Product Overview
Use: Controlled screw tightening in the most common range 2.5 - 12 N m / 22.5 - 106 lbf in, For use in almost all industrial manufacturing areas, Features: Classified according to DIN EN ISO 6789-2:2017 Type II Class A, incl. traceable test certificate, calibrated to a maximum permissible deviation of +/- 3 % and thus more precise than the +/- 4 % required by the standard, Torque wrench with 1/4" square drive with ball lock DIN 3120 - A 6.3 similar to ISO 1174, for controlled right-hand tightening, Automatic short-path actuation with tactile impulse and audible signal, Lightweight plastic casing, made from high-grade, glass-fibre reinforced polyamide, with soft-grip handle, Dual scale with a scale graduation of 0,5 N m and 5 lbf in, Additional micrometre scale for setting interim values with N m, graduations of 0.05 N m, Window with a magnifying-glass effect, Locking button enables reliable locking of the torque setting, Scope of delivery: Torque wrench Typ MINI, With certificate acc. to DIN EN ISO 6789:2017 Type II, traceable via in-house DAkkS laboratory to national standards
