30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
- Lower bound
Material
Aluminum Alloy
Trigger Mechanism
Short path triggering
Graduation
5.1.1900
Torque Wrench Type
A-SE A+S
1000 v insulated
31.12.1899
Calibration length
302 mm
Customs tariff number
82041100
Depth gauge [metric]
17,5 mm
Distance housing - square drive
40 mm
Drive connector rectangular
9 x 12 mm
Drive type/drive
Rectangular cavity
Fixed setting
1.1.1900
Graduation [lbf·in]
50 lbf·in
Head height 1 [mm]
30 mm
Lever length drive side [mm]
40 mm
Lever length handle side [mm]
321 mm
Net weight [kg]
0,95 kg
Precision +/-
+/- 3 %
Range of application
Assembly Series assembly Production
Reach registration available
31.12.1899
Scale division [n-m]
5 N·m
Storage/content
Plastic box
Target groups
Automotive Industry Construction and commercial vehicles Military Mechanical engineering Railway Oil & Gas
Test certificate
DIN EN ISO 6789-2:2017
Tightening direction
Left and right
Torque (max.) [lbf·in]
70 lbf·in
Torque (max.) [n·m]
40 N·m
Torque (min.) [lbf·in]
50 lbf·in
Torque (min.) [n·m]
8 N·m
Torque range (min./max.) [lbf·ft]
-
Torque range (min./max.) [lbf·in]
70 lbf·in - 50 lbf·in
Torque range (min./max.) [n·m]
8 N·m - 40 N·m
Total height [mm]
30 mm
Total length [mm]
361 mm
Total width [mm]
35 mm
Vde certified
31.12.1899
Width of head 1 [mm]
35,0 mm
Product Overview
Technical advantage/Function: Pre-set value locking and safety device (A+S) eliminates the possibility of unintentional or manipulated adjustment, thereby representing more process reliability of the user, Classified as per DIN EN ISO 6789-2:2017 Type II Class A; adjusted to a maximum permissible +/-3% deviation and thus with a greater precision than the standard-stipulated +/-4%, Lightweight yet robust (as the housing is made of an aluminum alloy) and resilient, very workshop-friendly, Drive offers extensive range of accessories, Depending on the application, access is possible from the front (e.g. open-end fitting) or side (e.g. reversible ratchet and socket)., Force to be applied in the middle of the handgrip only - do not use an extension tube as otherwise, inaccuracies can evolve, Operation only with end fittings otherwise inaccuracies can arise. Keep the depth gauges on the certificate in mind. Only use original GEDORE accessories., Extremely low wear attributable to reduced forces in a lever mechanism, Forged lever chain from our group own quality forge, Maximum precision even when subjected to extreme continuous use, Long life cycles and tool lives, Easy operation - fast and safe torque tightening, Easy adjustment thanks to attractive adjusting button secured against loss at the end of the handle, With certificate acc. to DIN EN ISO 6789-2:2017, traceable via in-house DAkkS laboratory to national standards, Pre-set DREMOMETER for serial production wherever the same value always needs to be applied, If ordering, please specify the N m value - if a fixed factory pre-setting is desired (price on request)
