Features
- Lower bound
Number of Teeth
17.2.1900
Material
Steel tube construction with high-quality plastic parts
Trigger Mechanism
Short path triggering
Graduation
10.1.1900
1000 v insulated
31.12.1899
Calibration length
500,2 mm
Customs tariff number
82041100
Distance housing - square drive
21,3 mm
Drive connector square (male)
1/2" | 12,5 mm
Drive type/drive
Reversible ratchet
Fixed setting
31.12.1899
Head height 1 [mm]
22 mm
Net weight [kg]
1,74 kg
Precision +/-
+/- 3 %
Range of application
Assembly Maintenance and repair
Reach registration available
31.12.1899
Return angle
7,5 °
Target groups
Automotive Industry Construction and commercial vehicles Consumer Energy Mechanical engineering Workshop Service Agriculture Oil & Gas Utilities
Test certificate
DIN EN ISO 6789-2:2017
Tightening direction
Right
Torque (max.) [n·m]
300 N·m
Torque (min.) [n·m]
60 N·m
Torque range (min./max.) [n·m]
60 N·m - 300 N·m
Total height [mm]
44 mm
Total length [mm]
590 mm
Total width [mm]
44 mm
Vde certified
31.12.1899
Vernier nm
1 N·m
Width of head 1 [mm]
42,5 mm
Product Overview
Adjustable, releasing and sturdy tubular torque wrench with integrated lever ratchet and with square drive for industry and the trades, Classified according to DIN EN 6789:2017 Type II Class A, calibrated to a maximum permissible deviation of +/- 3 % and thus more precise than the +/- 4 % required in the standard, Incl. test certificate according to DIN EN ISO 6789-2:2017, For controlled directional tightening
