Features
- Lower bound
Width of hooked foot [mm]
22 mm
Width across flats [mm]
17 mm
Version/execution
2-arm pattern
Vde certified
31.12.1899
Usable depth of hooked foot d2 [mm]
12 mm
Usable clamping reach [mm]
100 mm
Tractive force (max.) [t]
5.1.1900
Thickness of hooked foot at tip
3,0 mm
Spindle width across flats
17 mm
Spindle thrust piece type
Kugel & Spitze
Spindle thread length (usable) [mm].
140 mm
Spindle surface coating
Nitro-carburated
Spindle holder
M14x1,5mm
Spindle anti-slip device
31.12.1899
Reversible arms available
1.1.1900
Reach registration available
31.12.1899
Quick release lever available
1.1.1900
Net weight [kg]
1,2 kg
Load of the entire puller (max.) [t]
5 t
Hydraulic spindle optional
-
Hook can be moved parallel
1.1.1900
Hook brake available
31.12.1899
Exchangeable spindle tip
1.1.1900
Customs tariff number
82055980
Clamping width a2 (min.) internal pulling [mm]
70 mm
Clamping width a2 (max.) internal pulling [mm]
170 mm
Clamping width (max.) external pulling [mm]
130 mm
Clamping bracket available
31.12.1899
Can be retrofitted with hydraulic spindle
31.12.1899
Anti-slip device on the spindle
31.12.1899
3d data available
31.12.1899
1000 v insulated
31.12.1899
Spindle Thread Size
M14x1,5x140mm
Graduation
x
Use
For removing drive pulleys, wheels, ball bearings etc.
Number of Arms
2.1.1900
Screws Included
31.12.1899
Number Of Hooks
2.1.1900
Product Overview
Strong drop forged pattern, By reversing the legs, this tool can be used as an internal or external puller, Scale for uniform adjustment of the puller legs. Allows centred pulling, with optimised application of force, even when extremely high pulling forces are required, Integral legs, with quick-release, Spindle with replaceable ball and tip, Spindle thermo-chemically hardened, Upgradeable with hydraulic spindle (see table)
