Features
- Lower bound
Number of Teeth
5.2.1900
Material
Tubular steel construction
Trigger Mechanism
Long travel triggering
1000 v insulated
31.12.1899
Customs tariff number
82041100
Drive connector square (male)
3/4" | 20 mm
Drive type/drive
Push-through square
Fixed setting
31.12.1899
Graduation [lbf·ft]
10 lbf·ft
Net weight [kg]
10 kg
Precision +/-
+/- 4 %
Range of application
Assembly Maintenance and repair
Reach registration available
31.12.1899
Return angle
10 °
Scale division [n-m]
20 N·m
Storage/content
Plastic case
Target groups
Automotive Industry Construction and commercial vehicles Consumer Military Mechanical engineering Utilities Service Railway Agriculture Oil & Gas
Tightening direction
Left and right
Torque (max.) [lbf·ft]
500 lbf·ft
Torque (max.) [n·m]
700 N·m
Torque (min.) [lbf·ft]
100 lbf·ft
Torque (min.) [n·m]
150 N·m
Total height [mm]
55 mm
Total length [mm]
1.250 mm
Total width [mm]
95 mm
Vde certified
31.12.1899
Product Overview
Use: Controlled screw tightening in the most common range of 150 - 1000 N m, Industry and vehicle sector (lorries, industrial vehicles), Features: Adjustable torque wrench - with scale, 3/4" square drive with integrated ratchet function, Suitable for bi-directional tightening on account of push-through square drive, Working accuracy: +/- 4 % tolerance of set torque, Acc. to DIN EN ISO 6789, traceable to national standards, Breaking mechanism as an actuation signal which can be seen and felt and makes over-tightening unlikely, Dual scale N m and Ibf ft, Scope of delivery: Torque wrench Typ 88 KNICKER, Test certificate acc. to DIN EN ISO 6789, Delivery in sturdy plastic case
