ADS 12 DS Torque wrench type 83 1/4" 2.4-12 Nm

Roll over image to zoom in

Gedore 3108457 ADS 12 DS Torque wrench type 83 1/4" 2.4-12 Nm

Item #: 3108457 by Gedore

Brand: Gedore

UPC #: 611702890372

See reviewsSee reviews
See reviews summary

$462.16

/each
SAVE UP TO 46.22
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Lower bound

1000 v insulated

31.12.1899

Customs tariff number

82041100

Drive connector square (male)

1/4" | 6,3 mm

Drive type/drive

Double square ratchet

Epa-/esd-model

1.1.1900

Evaluation software

31.12.1899

Fixed setting

31.12.1899

Graduation [lbf·in]

2 lbf·in

Graphic display

31.12.1899

Net weight [kg]

0,52 kg

Range of application

Production Quality control Maintenance and repair

Reach registration available

31.12.1899

Scale division [n-m]

5 N·m

Target groups

Automotive Electronics industry Industry Construction and commercial vehicles Military Mechanical engineering Service

Torque (max.) [lbf·in]

24 lbf·in

Torque (max.) [n·m]

12 N·m

Torque (min.) [lbf·in]

120 lbf·in

Torque (min.) [n·m]

2,4 N·m

Torque range (min./max.) [n·m]

2,4 N·m - 12 N·m

Total height [mm]

61 mm

Total length [mm]

244 mm

Vde certified

31.12.1899

Product Overview
Use: Controlled tightening and verification of tightening values, For use in almost all industrial manufacturing areas, Dual scale. Dial provides effective measurement in Metric and Imperial torque units in both directions, delivering flexibility and minimising tool investment, Features: Dial-indicating torque wrench with dual scale and slave pointer, 1/4", 3/8", 1/2", 3/4" or 1" double square drive with ball lock for controlled right and left tightening, Versatile usage. Use for Maintenance, Repair, Assembly and Quality Control, For controlled screw tightening and torque measurements, Display accuracy: +/- 4 % tolerance of the indicated value, Acc. to DIN EN ISO 6789, traceable to national standards, With dual scale in N m and lbf in or lbf ft double-tinted clearly readable face, 5 % overload of the maximum value, Housing made of light, robust special aluminum construction - painted silver-grey, Black, non-slip rubber handgrips, Model No. ADS 4 to No. ADS 40: EPA (Electrostatic Protected Area) compliant, for use in electrostatically sensitive applications, With audio-visual signal, Test certificate acc. to DIN EN ISO 6789
