Features
- Lower bound
Trigger Mechanism
Friction clutch
1000 v insulated
31.12.1899
Cross-handle available
1.1.1900
Customs tariff number
82041100
Drive connector hexagon female (metric)
6,3 mm
Drive connector hexagon female [inch]
1/4"
Drive type/drive
Bitholder
Epa-/esd-model
31.12.1899
Fixed setting
1.1.1900
Net weight [kg]
0,32 kg
Precision +/-
+/- 6 %
Range of application
Assembly Quality control Maintenance and repair Testing and trial departments
Reach registration available
1.1.1900
Target groups
Automotive Electronics industry Industry Military
Test certificate
DIN EN ISO 6789-2:2017
Tightening direction
Left and right
Torque (max.) [n·m]
13,6 N·m
Torque (min.) [n·m]
2,5 N·m
Torque range (min./max.) [cn·m]
-
Torque range (min./max.) [n·m]
2,5 N·m - 13,6 N·m
Total length [mm]
137 mm
Vde certified
31.12.1899
Product Overview
Controlled screw tightening in the range of 2.5 - 13.6 Nm, Torque screwdrivers suitable for clean rooms, Mechanical parts made of stainless steel or suitably coated, Use of PTFE impregnated and anodized aluminum handles, Right and left tightening, Precision mechanism glides through clearly noticeably when the set value is reached - overdrawing is not possible, The pre-setting can be made at the factory or by the user on suitable torque testers, If ordering, please specify the N m value - if a fixed factory pre-setting is desired (price on request)
