ETQ 600 Electronic torque wrench E-torc Q 100-600 Nm Z 22

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Gedore 3122344 ETQ 600 Electronic torque wrench E-torc Q 100-600 Nm Z 22

Item #: 3122344 by Gedore

Brand: Gedore

UPC #: 4002805937662

See reviewsSee reviews
See reviews summary

$11,327.03

13,091.80 /each
SAVE UP TO 1132.70
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Custom Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Lower bound

Measurement accuracy

± 1% Toleranz vom Ablesewert, ± 1 Digit

Type of battery

22.1.1951

Energy source

Akku

1000 v insulated

31.12.1899

Chemical properties

Li-Ion

Customs tariff number

82041100

Distance middle of handgrip to pivot point

987 mm

Drive connector pin

22 mm

Drive type/drive

Drive pin

Epa-/esd-model

31.12.1899

Evaluation software

1.1.1900

Fixed setting

31.12.1899

Graphic display

1.1.1900

Head height 1 [mm]

22 mm

Measuring accuracy angle of rotation

±1% , min. ±1° auf 360° bei mind. 4°/sec.

Net weight [kg]

3,55 kg

Precision +/-

+/- 1 %

Range of application

Assembly Series assembly Production Quality control Maintenance and repair Bolting case analysis

Reach registration available

31.12.1899

Section at take e way

Rub. 205 Sec.Li-Io 0-50g

Target groups

Automotive Electronics industry Industry Construction and commercial vehicles Military Energy Mechanical engineering Service Railway

Tightening direction

Left and right

Torque (max.) [n·m]

600 N·m

Torque (min.) [n·m]

100 N·m

Torque range (min./max.) [n·m]

100 N·m - 600 N·m

Total height [mm]

42,5 mm

Total length [mm]

1.058 mm

Total width [mm]

79 mm

Un number

UN 3481

Vde certified

31.12.1899

Width of head 1 [mm]

22,0 mm

Product Overview
The features, Practical range of functions that covers almost all requirements, All the standard measurement methods: Torque, Torque/rotary angle, Loosening/tightening, Continued application of force, Yield point, Powerful lithium-ion battery with quick release system, 2D-Scanner (optional), Housing rotatable by 60 degree each, Data management in XML format, The user interfaces, Large TFT graphic display, 109 mm (4.3") diagona, Curve display and evaluation directly on the measuring device possible, Touch function or hardware keys for operating, Powerful PC operating software (from Windows 7), The communication, Radio (WiFi 2,4 und 5 GHz), USB mini interface, Attachment to CAQ systems (optional), The accuracy, Factory calibration certificate according to DIN ISO 6789 type 1 class C, Calibration certificate DAKkS DKDR 3-7 Class 1 (optional), Scope of delivery: Electronic torque wrench E-torc Q, Battery ETQ APW, USB cable
