Features
- Lower bound
Number of Teeth
17.2.1900
Trigger Mechanism
Short path triggering
Graduation
10.1.1900
1000 v insulated
31.12.1899
Calibration length
485,2 mm
Customs tariff number
82041100
Distance housing - square drive
23 mm
Drive connector square (male)
1/2" | 12,5 mm
Drive type/drive
square socket with knob, serrated
Fixed setting
31.12.1899
Head height 1 [mm]
35,9 mm
Net weight [kg]
1,541 kg
Precision +/-
+/- 3 %
Range of application
Assembly Maintenance and repair
Reach registration available
31.12.1899
Return angle
7,5 °
Target groups
Automotive Industry Construction and commercial vehicles Consumer Energy Mechanical engineering Workshop Service Agriculture Oil & Gas Utilities
Test certificate
DIN EN ISO 6789-2:2017
Tightening direction
Left and right
Torque (max.) [n·m]
300 N·m
Torque (min.) [n·m]
60 N·m
Torque range (min./max.) [n·m]
60 N·m - 300 N·m
Total height [mm]
47 mm
Total length [mm]
575 mm
Total width [mm]
52 mm
Vde certified
31.12.1899
Vernier nm
1 N·m
Version/execution
square socket with knob, serrated
Width of head 1 [mm]
46,0 mm
Product Overview
Use: Controlled screw tightening from 60 to 300 Nm, Repetition-accurate and precision-like, Audible Torque triggering can clearly be heard and felt, Clockwise and anti-clockwise tightening from switching over the mushroom head/push-through square, Features: Adjustable torque wrench with square drive and integrated ratchet function, Square drive with ratchet mechanism, Torque is set by turning the handle, The set value is fixed through the lock at the end of the handle, Easy-to-read scale with magnifying glass for N m, plus 1/10 scale for precision setting, Tripping accuracy: /-3 % tolerance of the set scale value, Scope of delivery: Torque wrench with test certificate acc. to DIN EN ISO 6789, Operating instructions
