Features
- Lower bound
Usable Length
192 mm
Support
1.36/4 1.35/3
1000 v insulated
31.12.1899
3d data available
31.12.1899
Width of hooked foot [mm]
33 mm
Width of head 1 [mm]
70,0 mm
Width across flats [mm]
36 mm
Vde certified
31.12.1899
Usable depth of hooked foot d2 [mm]
5 mm
Usable clamping reach [mm]
187 mm
Total length [mm]
230 mm
Total height [mm]
269 mm
Thickness of hooked foot at tip
6,0 mm
Spread range
60-160
Reversible arms available
31.12.1899
Reach registration available
31.12.1899
Net weight [kg]
2,312 kg
Effective effective hook length [mm]
213 mm
Customs tariff number
82055980
Connecting thread
G 1/2"
Clamping bracket available
31.12.1899
Product Overview
Operation: The extraction jaws are spread by turning the nut. The newly-developed spreading system enables a simple, step-free and time-saving adjustment to the desired diameter to be made. The sharp-edged sections of the extraction jaws seat flush beneath when spread, Both internal extractors can be used with sliding hammer 1.35/3, Adapter 135/325-I M16x1,5 G 1/2" (Code 1123750) must also be ordered if sliding hammer 1.35/3 is used., Both internal extractors can be used with the slide hammer 1.35/3, If slide hammer No. 1.35/3 is used, the adaptor No. 135/325-I M16x1.5 G 1/2" (Code 1123750) must be ordered as well
