Features
- Lower bound
1000 v insulated
31.12.1899
Backflow protection
31.12.1899
Customs tariff number
82041100
Distance output square - end of reaction arm (max)
4.4.1900
Distance output square - start reaction arm (min.)
25.2.1900
Drive connector square (male)
1/2"
Drive connector square female (metric)
12,5 mm
Drive connector square female [inch]
1/2"
Eingangskraft [n·m]
270 N·m
Input force [lbf·ft]
200 lbf·ft
Multiplication at the ratio
31.12.1899
Net weight [kg]
1,3 kg
Output square
3/4"
Output square (inch)
3/4"
Output square (metric)
20 mm
Output torque (max.) [lbf-ft]
7.8.1902
Output torque (max.) [n-m]
23.7.1903
Reach registration available
31.12.1899
Total height with reaction arm (max.)
21.6.1900
Total height with reaction arm (min.)
13.6.1900
Total height without reaction arm
12.5.1900
Total length [mm]
230 mm
Total width without reaction arm
20.3.1900
Vde certified
31.12.1899
Version reaction arm
Z-Form, cranked
Wide torque multiplier
20.3.1900
Product Overview
Especially suitable for: Industry, construction sites, car and truck garages, agricultural technology, Bridge, ship, aircraft and railway construction, refineries, Machinery and plant engineering, maintenance, Features: Mechanical hand torque multiplier for controlled screw tightening and unloosening screw connections, With a single-stage planet gear, High-performance aluminum housing, With Z-form, offset reaction arm of chrome-vanadium steel, Can be optionally retrofitted with L-form straight reaction arm - with adjustable reaction arm - of lightweight metal, Model with transmission ratio 1:5, Guaranteed accuracy: Better than +/- 3 % tolerance, To operate with a suitable torque wrench, 1 turning rod 354 mm, d 22 mm, No. E-28 LRZ-DS, Also available as set (No. DVV-13ZG) with three different Impact sockets SW 27, 30, 32 mm, Output square with hole for Impact sockets with locking pin and ring
Parts list: Torque multiplier DREMOPLUS ALU
Delivery in stable box on pallet
Adjustment table
Detailed technical information is available on request
