Features
- Lower bound
Width of head 2 [mm]
75,2 mm
Width of head 1 [mm]
53,0 mm
Width across flats 1 [af]
1.7/16"
Vde certified
31.12.1899
Total width [mm]
75 mm
Total length [mm]
460 mm
Total height [mm]
44 mm
Ring offset
10°
Reach registration available
31.12.1899
Net weight [kg]
1,085 kg
Mouth position 1
15°
Height of offset 1
43 mm
Head height 2 [mm]
12,8 mm
Head height 1 [mm]
23,5 mm
Customs tariff number
82041100
1000 v insulated
31.12.1899
Standard
similar to DIN 3113 - form B ISO 3318 ISO 7738
Weight
2,390 lbs
Material
31CrV3
Product Overview
GEDORE vanadium steel 31CrV3, chrome-plated, With same size each end, Chrome-vanadium steel 31CrV3, chrome-plated, Satin non-glare finish, Carefully forged and professionally machined, Ring: cranked and 10 degree angled, with UD profile for gentle power transmission, from SW 1.3/8" 12-edge ring, Jaw: ground precisely to exact nominal size for optimum contact areas, Slim ribbed open end for added strength guarantees maximum torques, Overloading indicated by deformation, The offset ring ensures a better grip on deep-seated or inset nuts or bolts, Top-grade industrial quality for the hardest of continuous use
