30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
- Lower bound
Version/execution
incl. switching sleeve and connection cable
Vde certified
31.12.1899
Total length [mm]
133 mm
Torque (min.) [n·m]
2 N·m
Torque (min.) [lbf·in]
89 lbf·in
Torque (max.) [n·m]
10 N·m
Torque (max.) [lbf·in]
17,8 lbf·in
Tightening direction
Left and right
Test certificate
DIN EN ISO 6789-02:2017
Target groups
Automotive Industry
Reach registration available
31.12.1899
Range of application
Assembly Series assembly Production Quality control
Precision +/-
+/- 6 %
Net weight [kg]
0,15 kg
Fixed setting
1.1.1900
Epa-/esd-model
31.12.1899
Drive type/drive
Rectangular cavity
Drive connector rectangular
9 x 12 mm
Customs tariff number
82041100
1000 v insulated
31.12.1899
Trigger Mechanism
Long travel triggering
Material
Tubular steel construction
Product Overview
Especially for remote switching, counting, monitoring and control on production lines and series production, Controlled screw tightening in the range of 2 -10 N m, With 9x12 mm rectangular-cavity-end, Fixed, presettable torque wrench - without scale, The fixed setting can be carried out in the factory or by hand using suitable test equipment, If a factory setting is required, please specify the Nm value when ordering (price on request), Including setting tool to change the fixed value
