Features
- Lower bound
Trigger Mechanism
Friction clutch
1000 v insulated
31.12.1899
Cross-handle available
31.12.1899
Customs tariff number
82041100
Drive connector hexagon female (metric)
6,3
Drive connector hexagon female [inch]
1/4"
Drive type/drive
Bitholder
Epa-/esd-model
31.12.1899
Fixed setting
1.1.1900
Net weight [kg]
0,335 kg
Precision +/-
+/- 6 %
Range of application
Assembly Production Quality control Series assembly Maintenance and repair
Reach registration available
31.12.1899
Target groups
Automotive Electronics industry Industry Precision mechanics Military Service
Test certificate
DIN EN ISO 6789-2:2017
Tightening direction
Left and right
Torque (max.) [n·m]
6 N·m
Torque (min.) [n·m]
1 N·m
Torque range (min./max.) [cn·m]
-
Torque range (min./max.) [n·m]
1 N·m - 6 N·m
Total height [mm]
35 mm
Total length [mm]
184 mm
Vde certified
31.12.1899
Product Overview
Use: Controlled screw tightening in the most common range of 1 - 6 N m, High-speed, controlled tightening enables serial production, Electrical and electronic hardware industry, instrument-making industry and industrial manufacturing or in quality control, Features: Adjustable torque screwdriver - with scale, With 1/4" female hexagon drive for use with 1/4" hexagon bits as per DIN 3126 - C 6.3, With adaptor also suitable for 1/4" square drive sockets as per DIN 3124, Working accuracy: +/- 6 % tolerance of set torque, Acc. to DIN EN ISO 6789, traceable to national standards, Precision radial ball clutch and cam design for controlled bi-directional tightening, Precision mechanism slips very noticeably when the pre-set value is achieved, Automatic resetting to the starting position, 3 models in the range 0,2 N m to 9 N m, Micrometre scale graduation: 1 cN m resp. 0,1 N m, Lightweight construction by virtue of anodised aluminum handgrips, Scope of delivery: Torque screwdriver Typ 757, 1/4" square/hexagon drive adaptor (No. 757-20), Models 757-06/-09 with additional sliding T-bar for ease of use, Test certificate acc. to DIN EN ISO 6789, Delivery in sturdy cardboard packaging
