8559-01 Torque wrench DREMOMETER AML 1/4" 6-30 Nm

Roll over image to zoom in

Gedore 7775870 8559-01 Torque wrench DREMOMETER AML 1/4" 6-30 Nm

Item #: 7775870 by Gedore

Brand: Gedore

UPC #: 4002805855911

See reviewsSee reviews
See reviews summary

$562.24

/each
SAVE UP TO 56.22
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Lower bound

Width of head 1 [mm]

30,0 mm

Vde certified

31.12.1899

Total width [mm]

30 mm

Total length [mm]

268 mm

Total height [mm]

51 mm

Torque range (min./max.) [n·m]

6 N·m - 30 N·m

Torque range (min./max.) [lbf·in]

50 lbf·in - 270 lbf·in

Torque range (min./max.) [lbf·ft]

-

Torque (min.) [n·m]

6 N·m

Torque (min.) [lbf·in]

270 lbf·in

Torque (max.) [n·m]

30 N·m

Torque (max.) [lbf·in]

50 lbf·in

Tightening direction

Left and right

Target groups

Automotive Electronics industry Precision mechanics Military Energy Mechanical engineering Workshop Service Agriculture Control cabinet construction

Storage/content

Plastic box

Scale division [n-m]

1 N·m

Reach registration available

31.12.1899

Range of application

Assembly Series assembly Production Maintenance and repair

Precision +/-

+/- 3 %

Net weight [kg]

0,553 kg

Head height 1 [mm]

30 mm

Graduation [lbf·in]

10 lbf·in

Fixed setting

31.12.1899

Drive type/drive

Double square rigid

Drive connector square (male)

1/4" | 6,3 mm

Distance housing - square drive

15 mm

Customs tariff number

82041100

Calibration length

206 mm

1000 v insulated

31.12.1899

Torque Wrench Type

AML

Trigger Mechanism

Short path triggering

Product Overview
Use: Controlled screw tightening in the range from 6 - 30 N m / 50 - 270 lbf in, Features: Classified according to DIN EN ISO 6789-2:2017 Type II Class A, incl. traceable test certificate, calibrated to a maximum permissible deviation of +/- 3 % and thus more precise than the +/- 4 % required by the standard, 1/4" square drive with ball locking device as per DIN 3120 - A 6.3 ISO 1174, Automatic short-path actuation with tactile impulse and audible signal, Dual scale with a scale graduation of 1 N m and 10 lbf in, Technical advantage/Function: Lightweight yet robust (as the housing is made of an aluminum alloy) and resilient, very workshop-friendly, No inaccuracies whether used with both hands or held away from the handle (as for standard torque wrenches), Both the square drive and fulcrum are on an axis which ensures a high degree of user safety; can be extended to reduce the user's working load., Extremely low wear attributable to reduced forces in a lever mechanism, Forged lever chain from our group own quality forge, Maximum precision even when subjected to extreme continuous use, Long life cycles and tool lives, Easy operation - fast and safe torque tightening, Easy adjustment thanks to attractive adjusting button secured against loss at the end of the handle
