Features
- Lower bound
Width of hooked foot [mm]
30 mm
Width across flats [mm]
22 mm
Vde certified
31.12.1899
Usable depth of hooked foot d2 [mm]
18 mm
Usable clamping reach [mm]
150 mm
Tractive force (max.) [t]
5,0
Total width [mm]
250 mm
Total length [mm]
260 mm
Total height [mm]
50 mm
Thickness of hooked foot at tip
3,5 mm
Spindle anti-slip device
31.12.1899
Reversible arms available
1.1.1900
Reach registration available
31.12.1899
Quick release lever available
31.12.1899
Net weight [kg]
3,5 kg
Hydraulic spindle optional
1.06/HSP1
Hydraulic spindle available
31.12.1899
Hook can be moved parallel
31.12.1899
Hook brake available
31.12.1899
Exchangeable spindle tip
31.12.1899
Customs tariff number
82055980
Clamping width a2 (min.) internal pulling [mm]
90 mm
Clamping width a2 (max.) internal pulling [mm]
260 mm
Clamping width (max.) external pulling [mm]
200 mm
Clamping bracket available
31.12.1899
Can be retrofitted with hydraulic spindle
1.1.1900
Anti-slip device on the spindle
31.12.1899
3d data available
31.12.1899
1000 v insulated
31.12.1899
Spindle Thread Size
G 1/2 x 210
Graduation
x
Number of Arms
2.1.1900
Screws Included
31.12.1899
Product Overview
Strong drop forged design, Scale for uniform adjustment of the puller legs. Allows centred pulling, with optimised application of force, even when extremely high pulling forces are required, By reversing the legs, this tool can be used as an internal or external puller, Extra or replacement legs increase versatility, Upgradeable with hydraulic spindle (see table), Upgradeable with hydraulic spindle (see table)
