1.06/3-3 Universal puller, 2-arm, 250x300 mm

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Gedore 8001200 1.06/3-3 Universal puller, 2-arm, 250x300 mm

Item #: 8001200 by Gedore

Brand: Gedore

UPC #: 4036976104257

See reviewsSee reviews
See reviews summary

$672.92

/each
SAVE UP TO 67.29
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Custom Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Lower bound

Number Of Hooks

2.1.1900

Screws Included

1.1.1900

Number of Arms

2.1.1900

Use

For removing drive pulleys, wheels, ball bearings etc.

Graduation

x

Width of hooked foot [mm]

36 mm

Width across flats [mm]

27 mm

Version/execution

2-arm with extended hooks

Vde certified

31.12.1899

Usable depth of hooked foot d2 [mm]

28 mm

Usable clamping reach [mm]

300 mm

Tractive force (max.) [t]

7,5

Total width [mm]

330 mm

Total length [mm]

450 mm

Total height [mm]

65 mm

Thickness of hooked foot at tip

6,5 mm

Spindle width across flats

27 mm

Spindle thrust piece type

Spitze

Spindle thread length (usable) [mm].

280 mm

Spindle surface coating

Nitro-carburated

Spindle holder

G3/4"

Spindle anti-slip device

31.12.1899

Reversible arms available

1.1.1900

Reach registration available

31.12.1899

Quick release lever available

31.12.1899

Net weight [kg]

9,1 kg

Load of the entire puller (max.) [t]

7,5 t

Hydraulic spindle optional

1.06/HSP2

Hook can be moved parallel

1.1.1900

Hook brake available

31.12.1899

Exchangeable spindle tip

31.12.1899

Customs tariff number

82055980

Clamping width a2 (min.) internal pulling [mm]

125 mm

Clamping width a2 (max.) internal pulling [mm]

330 mm

Clamping width (max.) external pulling [mm]

250 mm

Clamping bracket available

31.12.1899

Can be retrofitted with hydraulic spindle

1.1.1900

Anti-slip device on the spindle

31.12.1899

3d data available

31.12.1899

1000 v insulated

31.12.1899

Spindle Thread Size

G3/4x280mm

Product Overview
Scale for uniform adjustment of the puller legs. Allows centred pulling, with optimised application of force, even when extremely high pulling forces are required, Extended legs, By reversing the legs, this tool can be used as an internal or external puller, Extra or replacement legs increase versatility, Upgradeable with hydraulic spindle (see table), Upgradeable with hydraulic spindle (see table)
