Features
- Lower bound
Width of hooked foot [mm]
32 mm
Width across flats [mm]
22 mm
Vde certified
31.12.1899
Usable depth of hooked foot d2 [mm]
20 mm
Usable clamping reach [mm]
390 mm
Tractive force (max.) [t]
8.1.1900
Total width [mm]
230 mm
Total length [mm]
450 mm
Total height [mm]
53 mm
Thickness of hooked foot at tip
3,5 mm
Swivel hook
31.12.1899
Spindle anti-slip device
31.12.1899
Reversible hooks
31.12.1899
Reversible arms available
31.12.1899
Reach registration available
31.12.1899
Net weight [kg]
5,1 kg
Hydraulic spindle optional
1.06/HSP1
Hook end with slot
31.12.1899
Hook brake available
31.12.1899
Customs tariff number
82055980
Clamping width (max.) external pulling [mm]
280 mm
Clamping bracket available
31.12.1899
Can be retrofitted with hydraulic spindle
1.1.1900
Automatic pressing
1.1.1900
Anti-slip device on the spindle
31.12.1899
3d data available
31.12.1899
1000 v insulated
31.12.1899
Spindle Thread Size
G 1/2 x 250
Number of Arms
2.1.1900
Screws Included
31.12.1899
Product Overview
With technical and economical benefits due to the variable clamping reach and automatic grip of the legs, Especially suited to removing V-belt pulley wheels and flywheels mounted on longer shafts, Upgradeable with hydraulic spindle (see table), Upgradeable with hydraulic spindle
