Features
- Lower bound
Number Of Hooks
2.1.1900
Screws Included
1.1.1900
Number of Arms
2.1.1900
Use
For removing drive pulleys, wheels, ball bearings etc.
Graduation
x
Spindle Thread Size
G1/2x210mm
1000 v insulated
31.12.1899
3d data available
31.12.1899
Anti-slip device on the spindle
31.12.1899
Can be retrofitted with hydraulic spindle
1.1.1900
Clamping bracket available
31.12.1899
Clamping width (max.) external pulling [mm]
200 mm
Clamping width a2 (max.) internal pulling [mm]
260 mm
Clamping width a2 (min.) internal pulling [mm]
90 mm
Customs tariff number
82055980
Exchangeable spindle tip
31.12.1899
Hook brake available
31.12.1899
Hook can be moved parallel
1.1.1900
Hydraulic spindle optional
1.06/HSP1
Load of the entire puller (max.) [t]
5 t
Net weight [kg]
4,5 kg
Quick release lever available
31.12.1899
Reach registration available
31.12.1899
Reversible arms available
1.1.1900
Spindle anti-slip device
31.12.1899
Spindle holder
G1/2"
Spindle surface coating
Nitro-carburated
Spindle thread length (usable) [mm].
210 mm
Spindle thrust piece type
Spitze
Spindle width across flats
22 mm
Thickness of hooked foot at tip
3,5 mm
Total height [mm]
48 mm
Total length [mm]
400 mm
Total width [mm]
260 mm
Tractive force (max.) [t]
5.1.1900
Usable clamping reach [mm]
300 mm
Usable depth of hooked foot d2 [mm]
18 mm
Vde certified
31.12.1899
Version/execution
2-arm with extended hooks
Width across flats [mm]
22 mm
Width of hooked foot [mm]
30 mm
Product Overview
Scale for uniform adjustment of the puller legs. Allows centred pulling, with optimised application of force, even when extremely high pulling forces are required, Extended legs, By reversing the legs, this tool can be used as an internal or external puller, Extra or replacement legs increase versatility, Upgradeable with hydraulic spindle (see table), Upgradeable with hydraulic spindle (see table)
