1.06/3A-4 Universal puller, 2-arm, 350x400 mm

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Gedore 8109160 1.06/3A-4 Universal puller, 2-arm, 350x400 mm

Item #: 8109160 by Gedore

Brand: Gedore

UPC #: 4036976103472

See reviewsSee reviews
See reviews summary

$788.88

/each
SAVE UP TO 78.89
Buying in bulk
Special Order*Usually ships in 1-2 weeks
QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Custom Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Lower bound

Number Of Hooks

2.1.1900

Screws Included

1.1.1900

Number of Arms

2.1.1900

Use

For removing drive pulleys, wheels, ball bearings etc.

Graduation

x

Spindle Thread Size

G3/4x280mm

1000 v insulated

31.12.1899

3d data available

31.12.1899

Anti-slip device on the spindle

31.12.1899

Can be retrofitted with hydraulic spindle

1.1.1900

Clamping bracket available

31.12.1899

Clamping width (max.) external pulling [mm]

350 mm

Clamping width a2 (max.) internal pulling [mm]

420 mm

Clamping width a2 (min.) internal pulling [mm]

125 mm

Customs tariff number

82055980

Exchangeable spindle tip

31.12.1899

Hook brake available

31.12.1899

Hook can be moved parallel

1.1.1900

Hydraulic spindle optional

1.06/HSP2

Load of the entire puller (max.) [t]

7,5 t

Net weight [kg]

11,1 kg

Quick release lever available

31.12.1899

Reach registration available

31.12.1899

Reversible arms available

1.1.1900

Spindle anti-slip device

31.12.1899

Spindle holder

G3/4"

Spindle surface coating

Nitro-carburated

Spindle thread length (usable) [mm].

280 mm

Spindle thrust piece type

Spitze

Spindle width across flats

27 mm

Thickness of hooked foot at tip

6,5 mm

Total height [mm]

65 mm

Total length [mm]

640 mm

Total width [mm]

420 mm

Tractive force (max.) [t]

7,5

Usable clamping reach [mm]

400 mm

Usable depth of hooked foot d2 [mm]

28 mm

Vde certified

31.12.1899

Version/execution

2-arm with extended hooks

Width across flats [mm]

27 mm

Width of hooked foot [mm]

36 mm

Product Overview
Scale for uniform adjustment of the puller legs. Allows centred pulling, with optimised application of force, even when extremely high pulling forces are required, Extended legs, By reversing the legs, this tool can be used as an internal or external puller, Extra or replacement legs increase versatility, Upgradeable with hydraulic spindle (see table), Upgradeable with hydraulic spindle (see table)
