Grade 1 Single Cylinder Deadbolt with Large Format Interchangeable Less Core with 12297 Latch and 10094 Strike Bright Brass Finish

Roll over image to zoom in

  • Product Features

  • Product Overview

  • Related Videos

  • Reviews

  • Questions & Answers

Schlage Commercial B660J 605 Grade 1 Single Cylinder Deadbolt with Large Format Interchangeable Less Core with 12297 Latch and 10094 Strike Bright Brass Finish

Item #: B660J 605 by Schlage Commercial

Brand: Schlage Commercial

See reviewsSee reviews
See reviews summary
In Stock

$223.87

/each
SAVE UP TO 22.39
Buying in bulk
QUICK SHIPPING*Usually ships in 1 business dayIn stock: 10 units available

Finish: Bright Brass

QTY
–
+
+ Add to Wishlist
Buy in Bulk & Save - See HowWatch Now
Get Custom Quote

Shop with Confidence

30 Days Easy Return. We are the largest supplier of the most adaptable, personalized hardware in the industry. We work hard to ensure you're satisfied with our products.

Safe Payment
WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
Features
  • Single Cylinder Deadbolt - Deadbolt Thrown or Retracted by Key from Outside or by Inside Turn Unit
  • ANSI Certified A156.36
  • 1-5/8" to 2" Door Range
  • UL Listed for 3 Hour Fire Door
  • Commercial Grade 1

Finish

Bright Brass

Function

Single Cylinder

Series

B600 Series

Backset

Adjustable Backset 2-3/8" and 2-3/4"

Strike

Square Corner Deadbolt Strike

Thickness

1-5/8 In. - 2 In.

Strike Number

10-094

Latch Number

12-631

Latch Type

Deadbolt

ANSI Function

E0151 - Single Cylinder Deadbolt

Special Marks

Full size/large format interchangeable core

Dust Box

None

Strike Width

1-1/8 In.

Latch Backset Dim

2-3/4 In.

Cylinder Type

Schlage FSIC Less Core

Lock Face Size

2-1/4 In. x 1-1/8 In.

Package Qty

1

Bolt Protection

1 In.

Color Code

605/US3

Strike Type

Flat

Strike Height

2-3/4 In.

Grade

Grade 1

ANSI/BHMA Standards

E0151

Keyway

E Keyway

Keyed

Yes

Keying

None (Select for Less Cylinder Options)

Cylinder

J - FSIC Less Core

Electronic

No

Standard Strike

10-094: Square corner, no box, 1-1/8" x 2-3/4"

Keys Included

2

Lock Type

Deadbolts

Duty Level

Heavy Duty

Cylinder and Keyways

6-pin Conventional Cylinder (C Keyway)

Segment

Door Hardware

Standard Latch

12-296: Deadbolts - Adjustable 2-3/8" or 2-3/4"- Square corner, 1-1/8" x 2-1/4", 1" Housing Diameter

Product Overview
Grade 1 Single Cylinder Deadbolt with Large Format Interchangeable Less Core with 12297 Latch and 10094 Strike Bright Brass Finish
